3.0 Electrical characteristics
3.1 Interface signals
The input signals can be applied in three different modes:
1). Video, H-sync & V-sync
2). Video & Composite Sync
3). Video with Sync On Green (composite Green video).
Video : 0.7 Vp-p, input impedance, 75 ohm
Sync. : Separate sync TTL level, input
impedance 2k2 ohm
Hor. sync Positive/Negative
Ver. sync Positive/Negative
Composite sync TTL level, input
impedance 2k2 ohm
Positive/Negative
3.2 Interface
3.2.1 Cable
The input signals are applied to the display through a
detachable shielded cable.
Length : 1.8 m +/- 50 mm (detachable)
Connector type : 15 pin D-Sub male to 15 pin D-Sub male, blue
IBM PS/2 standard (3 rows)
with DDC2B pin assignments
Sync On Green Composite Green video, 0.3 Vp-p for sync
Part.
3.2.2 Input connectors
