Spare Parts Lists
EN 21DVD755VR 2.
Spare Parts Lists
MECHANICAL DVD755VR /02
Various
250 9965 000 18503 CASE
260 9965 000 18504 FRAME
285 9965 000 18506 DOOR ASSEMBLY
300 9965 000 18507 POWER CORD
330 9965 000 18486
801 9965 000 18508 INSTRUCTION ASSEMBLY
900 9965 000 18509 REMOTE CONTROLLER
ASSEMBLY
FRONT PWB DVD755VR /02
Various
283 9965 000 18512 DOOR.CASE
284 4822 492 42785 SPRING DOOR
A43 9965 000 18511 PANEL
ASSEMBLY,FRONT[NORM
AL PA
CABLE ASSY DVD755VR /xx
Various
806 9965 000 18514 1200M/M PAL-PAL DOUBLE
SHIELD
810 9965 000 18513 COMBI ACC WITH BOX
(FOR I AND
821 9965 000 18515 1200M/M SCART-SCART
DOUBLE SHI
DVD MECHANICAL DVD755VR /xx
Various
004 9965 000 18549 HOLDER
010 9965 000 18550 CABLE,FLAT
026 9965 000 18552 TRAY
A01 9965 000 18546 CLAMP ASSEMBLY
A02 9965 000 18547 BASE ASSEMBLY
A03 9965 000 18548 BASE ASSEMBLY
A26 9965 000 18545 DECK ASSEMBLY,VIDEO
011A 9965 000 18551 CABLE,FLAT
SUB PWB DVD755VR /02
A46A 9965 000 18555 465202D7160F30 000000
00003000
C201 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C202 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C203 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C206 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C207 4822 124 23056 47µF 20% 16V
C208 4822 124 23056 47µF 20% 16V
C211 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C212 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C213 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C214 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C231 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C232 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C233 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C234 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C239 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C240 3198 017 31530 0603 50V 15nF COL R
C241 4822 124 23056 47µF 20% 16V
C243 4822 126 12223 560pF 50V
C244 4822 126 12223 560pF 50V
C245 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C251 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C252 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C253 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C254 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C255 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C257 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C258 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C259 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C260 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C261 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C262 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C263 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C264 3198 017 31530 0603 50V 15nF COL R
C265 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C266 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C267 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C268 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C269 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C270 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C271 9965 000 18559 390pF 50V J 1508 R/TP
C272 9965 000 18559 390pF 50V J 1508 R/TP
C273 9965 000 18560 0.033µF 50V K (X) 1508 R/
TP
C274 9965 000 18561 470pF 50V J 1508 R/TP
C276 9965 000 13794 SMD 10pF 5% 50V 0603
C277 3198 017 31530 0603 50V 15nF COL R
C278 4822 126 11669 27pF
C279 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C280 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C281 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C282 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C283 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C291 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C292 4822 124 23056 47µF 20% 16V
C293 4822 124 23056 47µF 20% 16V
C295 4822 124 11947 10µF 20% 16V
C296 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C297 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C298 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C401 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C402 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C403 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C404 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C405 4822 124 23056 47µF 20% 16V
C406 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C407 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C408 4822 124 40804 22µF 20% 63V
C409 4822 124 40804 22µF 20% 63V
C410 4822 124 40804 22µF 20% 63V
C411 4822 124 40804 22µF 20% 63V
C412 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C413 5322 126 11578 1nF 10% 50V 0603
C414 5322 126 11578 1nF 10% 50V 0603
C415 9965 000 18562 270pF 50V 5% 1608 R/TP
C416 9965 000 18562 270pF 50V 5% 1608 R/TP
C417 9965 000 18562 270pF 50V 5% 1608 R/TP
C418 9965 000 18562 270pF 50V 5% 1608 R/TP
C419 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C420 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C421 9965 000 18563 3900pF 50V K Z5U(E) 1608
R/TP
C422 9965 000 18563 3900pF 50V K Z5U(E) 1608
R/TP
C423 4822 124 40804 22µF 20% 63V
C424 4822 124 40804 22µF 20% 63V
C425 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C426 4822 124 12052 220µF 20% 6,3V
C502 5322 126 11583 10nF 10% 50V 0603
C503 5322 126 11583 10nF 10% 50V 0603
C504 5322 126 11583 10nF 10% 50V 0603
C505 5322 126 11583 10nF 10% 50V 0603
C506 9965 000 11253 CHIP 100P/50V (J) CH 0603
C507 5322 126 11583 10nF 10% 50V 0603
C508 9965 000 18564 2.2µF 16V 80%,-20% (F)
3216
C509 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C510 9965 000 11253 CHIP 100P/50V (J) CH 0603
C511 4822 124 23056 47µF 20% 16V
C513 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C514 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C515 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C516 9965 000 18564 2.2µF 16V 80%,-20% (F)
3216
C517 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C518 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C519 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C520 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C521 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C522 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C523 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C524 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C525 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C526 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C527 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C528 4822 124 23056 47µF 20% 16V
C530 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C531 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C532 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C533 4822 126 14507 18pF 5% 50V 0603
C534 2222 867 15339 0603 50V 33P 5%
C535 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C536 5322 126 11578 1nF 10% 50V 0603
C537 5322 126 11578 1nF 10% 50V 0603
C538 5322 126 11578 1nF 10% 50V 0603
C539 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C540 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C541 4822 124 11947 10µF 20% 16V
C542 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C543 4822 124 11947 10µF 20% 16V
C544 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C545 4822 124 11947 10µF 20% 16V
C554 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C555 4822 124 11947 10µF 20% 16V
C556 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C557 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C558 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C559 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C560 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C561 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C563 4822 124 12052 220µF 20% 6,3V
C564 4822 124 12052 220µF 20% 6,3V
C567 4822 126 13883 220pF 5% 50V
C568 4822 126 13883 220pF 5% 50V
C569 4822 126 13883 220pF 5% 50V
C575 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C576 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C577 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C578 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C579 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C580 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C581 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C582 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C583 4822 124 12052 220µF 20% 6,3V
C584 4822 126 11669 27pF
C585 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C586 9965 000 11253 CHIP 100P/50V (J) CH 0603
C587 9965 000 11253 CHIP 100P/50V (J) CH 0603
C589 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C590 4822 124 12052 220µF 20% 6,3V
C591 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C592 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C597 4822 122 33777 47pF 5% 63V
C5A1 4822 124 11947 10µF 20% 16V
C5A2 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C5C1 4822 124 23056 47µF 20% 16V
C5C2 4822 124 23053 1µF 20% 63V
C5C4 4822 124 23053 1µF 20% 63V
C5C5 4822 124 23053 1µF 20% 63V
C5C6 4822 124 23053 1µF 20% 63V
C5C7 4822 124 23053 1µF 20% 63V
C5C8 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C5C9 4822 124 40804 22µF 20% 63V
C5E0 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C601 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C602 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C603 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C604 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C605 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C606 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
D401 4822 130 80522 DAP202U
D601 9965 000 18565 RL104F TP RECTRON NON
400V 1A
F501 9965 000 18566 LFA20-2A1E473MT
MITSUBISHI MAT
L201 9965 000 18574 10µH 5% 4X5 TR5
L202 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L203 9965 000 18574 10µH 5% 4X5 TR5
L204 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L231 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L251 9965 000 18575 HB-1M2012-102JT
CERATECH TP
