Philips DVD755VR - Service Information for Eeprom IC Setting

1-5
SERVICE INFORMATION FOR EEPROM IC SETTING
MODEL NAME HEX BINARY
DVD755VR/00 OPT1 7C 00000000
OPT2 63 00000000
OPT3 89 00000000
OPT4 F1 00000000
OPT5 31 00000000
OPT6 48 00000000
DVD755VR/02 OPT1 7C 00000000
OPT2 63 00000000
OPT3 09 00000000
OPT4 F0 00000000
OPT5 62 00000000
OPT6 40 00000000
DVD755VR/05 OPT1 3C 00000000
OPT2 63 00000000
OPT3 89 00000000
OPT4 F1 00000000
OPT5 31 00000000
OPT6 48 00000000
DVD755VR/14 OPT1 3C 00000000
OPT2 6A 00000000
OPT3 89 00000000
OPT4 F7 00000000
OPT5 00 00000000
OPT6 50 00000000
WR : OK I : EXIT MOVE : F G
EDIT : DE
1. DETECT NEW EEPROM (OPTION EDIT
SCREEN)
- Eeprom EDIT screen automatically appears if
replacing Eeprom.
- Setup option data using the cursor Up/Down key
of a remote control.
(Setup upon BOM depending on OPT1~OPT6
model)
• Since an initial remote control is set to LG for LG
model, appropriately set option data using the
cursor Up/Down key.
• For PHILIPS model, change a remocon key by
using following JIG key.
PHILIPS MODEL : FRONT FF + FRONT REC
KEY(LG/PHILIPS CODE)
2. EEPROM WRITED COMPLETE SCREEN
- Writes data on EEPROM by using REMOCON
"OK".
- If completing the option data screen with a menu
key, Powering Off is automatically done and the
option edit screen is arranged.
3. PG ADJUST
1) Payback the SP standard tape
2) Press the “1” key on the Remote controller and
the “PLAY” key on the Front Panel at the same
time, then it goes into Tracking initial mode.
3) Repeat the above step(No.2), then it finishes
the PG adjusting automatically.
4) Stop the playback, then it goes out to PG
adjusting mode after mony the PG data.
4. EEPROM INITIAL
- SETUP is displayed in the field if pressing the
FRONT REC KEY with the remocon number
"CLEAR" key pressed in the status of no tape.
- AUTO SEARCH is done since the initial screen
of ACMS is serviced if powering On.
- Check basic operation (PLAY/RECORD...)
EEPROM option code No. setting EEPROM option code No. setting procedure
NAME HEX BINARY
OPT1 00 00000000
OPT2 00 00000000
OPT3 00 00000000
OPT4 00 00000000
OPT5 00 00000000
OPT6 00 00000000
WR : OK I : EXIT MOVE : F G
EDIT : DE
MASKROM : R00
EEPROM : R00 LG CODE
