Philips DVD755VR - Page 64

3-48 3-49
EEPIN PB REC EEPIN PB REC
EE PB REC
MODE
PIN NO.
25
26
27
28
29
30
31
32
33
34
5.6 V
5.6 V
5.54 V
4.16 V
1.46 V
2.1 V
1.35 V
4.7 V
4.8 V
(-) 0.002 V
5.58 V
5.58 V
5.5 V
4.32 V
1.46 V
1.99 V
1.35 V
4.7 V
4.8 V
0.001 V
5.59 V
5.59 V
5.5 V
4.51 V
1.46 V
2.07 V
1.35 V
4.7 V
4.8 V
0.000 V
Q301
BASE 0.01 V 0.013 V 0.79 V
EMITER 0.003 V 0.004 V 0.005 V
COLECTOR 4.83 V 4.82 V 1.02 V
Q302
BASE 4.85 V 4.18 V 4.75 V
EMITER 0.002 V 4.85 V 4.75 V
COLECTOR (-)2.79 V 4.8 V (-)25.5 V
Q303
BASE (-)2.76 V 0.7 V (-)25.6 V
EMITER (-)0.8 V 0.007 V (-)19.13 V
COLECTOR 0.002 V 0.012 V 0.004 V
Q304
BASE (-)2.62 V 0.72 V (-)25.4 V
EMITER 0.002 V 0.002 V (-)19.4 V
COLECTOR 0.002 V 0.004 V 0.004 V
Q305
BASE 1.71 V 1.41 V 1.7 V
EMITER 2.41 V 2.1 V 2.39 V
COLECTOR 0.003 V 0.004 V 0.005 V
Q308
BASE 1.81 V 01.56 V 6.07 V
EMITER 2.47 V 6.06 V 6.07 V
COLECTOR 0.005 V 0.005 V 0.005 V
Q309
BASE 2.18 V 2.01 V 2.33 V
EMITER 2.87 V 2.7 V 3 V
COLECTOR 0.012 V 0.005 V 0.012 V
Q310
BASE 0.02 V 3.89 V 0.017 V
EMITER 0.005 V 0.004 V 0.005 V
COLECTOR 2.92 V 0.008 V 2.91 V
Q501
BASE 0.69 V 0.69 V 0.69 V
EMITER 0.002 V 0.003 V 0.003 V
COLECTOR 0.02 V 0.012 V 0.023 V
Q502
BASE 0.31 V 0.38 V 0.33 V
EMITER 0.004 V 0.004 V 0.004 V
COLECTOR 2.65 V 1.93 V 2.4 V
Q504
BASE 0.59 V 0.51 V 0.50 V
EMITER 0.03 V 0.03 V 0.03 V
COLECTOR 3.78 V 3.75 V 3.71 V
Q5S1
BASE 0.006 V 0.005 V 0.003 V
EMITER 1.77 V 1.8 V 1.89 V
COLECTOR 2.41 V 2.1 V 2.4 V
Q515
BASE 4.94 V 0.5~4.3 V 0.4~4.9 V
EMITER 0.002 V 0.003 V 0.005 V
COLECTOR 0.02 V 0.2~3.5 V 0.4~4.9 V
Q514
BASE 4.96 V 0.8~4.2 V 0.2~4.3 V
EMITER 0.002 V 0.002 V 0.003 V
COLECTOR 0.02 V 0.01~4.8V 0.011 V
Q7S1
BASE 0.007 V 0.007 V 0.008 V
EMITER 0.001 V 0.001 V 0.001 V
COLECTOR 3.7 V 3.5 V 0.057 V
Q801
BASE 0.7 V (-)0.1 V 0.01 V
EMITER 0.001 V 0.003 V 0.001 V
COLECTOR 0.004 V ~ 0.006 V
Q802
BASE 0.7 V (-)0.12 V 0.7 V
EMITER 0.001 V 0.001 V 0.001 V
COLECTOR 0.004 V 0.02 V 0.005 V
Q804
BASE 1.81 V 2.5 V 1.79 V
EMITER 2.5 V 3.20V 2.48 V
COLECTOR 0.002 V 0 V 0 V
Q901
BASE 0.005 V 0.005 V 0.006 V
EMITER 0.003 V 2.04 V 1.9 V
COLECTOR 0.003 V 0.004 V 0.005 V
Q902
BASE (-)1.64 V (-)1.69 V (-)1.79 V
EMITER 0.003 V 0.004 V 0.004 V
COLECTOR 0.004 V 0.004 V 0.005 V
Q903
BASE (-)1.74 V (-)1.63 V (-)1.8 V
EMITER 0.003 V 0.003 V 0.005 V
COLECTOR 0.003 V 0.004 V 0.005 V
