Philips DVD755VR - Page 99

3-89 3-90
PIN STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY
161 0 1.27
162 0 2.35
163 0 0
164 0 0.73
165 0 3.27
166 0 0.5
167 0 0
168 0 0.53
169 0 3.27
170 0 0.59
171 0 0
172 3.01 0.72
173 0 0.72
174 0 0
175 0 2.73
176 0 3.13
177 0 3.13
178 0 3.25
179 0 0
180 0 0
181 2.04 2.64
182 0 2.52
183 0 0
184 0 0.09
185 0 3.26
186 - -
187 0 0.08
188 0 0
189 0 0
190 0 0
191 0.23 0
192 0 3.29
193 0 0
194 0 0
195 0 0
196 0 0
197 0 1.63
198 0 0
199 0 0
200 0 2.15
201 0 1.44
202 0 1.44
203 0 1.43
204 0 1.43
205 0 1.42
206 0 2.1
207 0 2.07
208 0 1.41
209 0 1.52
210 0 1.43
211 0 2.81
212 0 3.28
213 0 0.12
214 0 0.12
215 1.02 1.43
216 0 1.43
STOP PLAY STOP PLAY STOP PLAY STOP PLAY
IC201
(MT1336E)
IC202
(MOTOR)
IC501
(MT1379)
IC502
(SDRAM)
IC505
(EEPROM)
IC510
(BUFFER)
IC5A1
(FLASH)
IC401
(CS4391)
IC402
(AMP)
IC5C1
(MM1623XFBE)
Q201 Q202 Q203 Q204
STOP PLAY STOP PLAY STOP PLAY STOP PLAY
E 0 0 0 0 0 0 5.14 4.34
C 0 5.09 0 0 0 0.19 0 2.42
B 0.68 0 0 5.04 5.04 0 5.08 3.64
Q205 Q501 Q6401
STOP PLAY STOP PLAY STOP PLAY
E 5.14 5.10 0 5.17 0
C 0.5 0 0 0 0 0.13
B 5.08 5.05 0.83 0.83 5.11 0
