Philips DVDR615 - IC7100 NCP301 LSNxx MOBO Board, Reset Circuit; IC7107 TMP87 CM74 AF MOBO Board, Microprocessor

Circuit-, IC descriptions and list of abbreviations
EN 142 DVDR615/699.
IC7100 NCP301LSNxx MOBO Board, Reset Circuit
Figure 9-11
IC7107 TMP87CM74AF MOBO Board, Microprocessor
Figure 9-12
Figure 1. Representative Block Diagrams
This device contains 25 active transistors.
NCP301xSNxxT1
Open Drain Output Configuration
V
ref
Input
Reset Output
Gnd
3
1
2
*
* The representative block diagrams depict active low reset output ‘L’ suffix devices. The comparato
r
inputs are interchanged for the active high output ‘H’ suffix devices.
