Philips DVDR615 Service Manual

Technical Specifications and Connection Facilities
EN 4 DVDR615/691.
Distortion and noise 16Hz-20kHz : >75dB
Intermodulation distortion : >70dB
Mute : >95dB
Outband attenuation: : >40dB above 30kHz
1.8 Digital Audio Output
1.8.1 Coaxial
CDDA/ LPCM (incl MPEG1) : according IEC958
MPEG2, AC3 audio : according IEC1937
DTS : according IEC1937,
amendment 1
1.8.2 Optical
CDDA/ LPCM (incl MPEG1) : according IEC958
MPEG2, AC3 : according IEC937
DTS : according IEC937,
amendment 1
1.9 Digital Video Input (IEEE 1394)
1.9.1 Applicable Standards
Implementation according:
IEEE Std 1394-1995
IEC 61883 - Part 1
IEC 61883 - Part 2 SD-DVCR (02-01-1997)
Specification of consumer use digital VCR’s using 6.3 mm
magnetic tape - dec.1994
Mechanical connection according:
Annex A of 61883-1
1.10 Dimensions and Weight
Height of feet : 5.5mm
Apparatus tray closed : WxDxH :435 x 285x 65mm
Apparatus tray open : WxDxH :435 x 422x 65mm
Weight without packaging : app. 4 kg ± 0.5 kg
Weight in packaging : app. 6.5 kg
1.11 Laser Output Power & Wavelength
1.11.1 DVD
Output power during reading : 0.8mW
Output power during writing : 20mW
Wavelength : 660nm
1.11.2 CD
Output power : 0.3mW
Wavelength : 780nm
http://www.jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Philips DVDR615 Specifications

Picture/Display

Aspect ratio	4:3, 16:9
D/A converter	10 bit, 54 MHz
A/D converter	10 bit, 54 MHz

Sound

D/A converter	24 bit, 96 kHz
A/D converter	24 bit, 96 kHz
Signal to noise ratio	90
Distortion and Noise (1kHz)	83 dB
Crosstalk (1kHz)	105 dB
Dynamic Range (1kHz)	83 dB

Power

Power supply	110V, 60Hz
Power consumption	27 W
Standby power consumption	< 4 W

Dimensions

Set dimensions (W x H x D)	435 x 285 x 65 mm
Set weight	3.5 kg
Packaging dimensions (W x H x D)	518 x 159 x 383 mm
Weight incl. Packaging	5.5 kg
