Philips DVDR615 - MISCELLANEOUS - SET EXPLODED VIEW

Spare Parts List
EN 168 DVDR615/6910.
MISCELLANEOUS - SET EXPLODED
VIEW
Various
101 3139 247 51831 BADGE PHILIPS ASSY
SILVER
102 3139 244 04761 CAB FRONT DVDR615/AP
110 3139 244 04561 BUTTON STANDBY
DVDR615
114 3139 244 04531 BUTTON EJECT DVDR615
118 3139 244 04521 BUTTON SET DVDR615
122 3139 244 04491 BUTTON CAP REC
DVDR615
126 3139 244 04511 RING REC DVDR615
130 3139 244 04501 LIGHT GUIDE REC
DVDR615
134 3139 244 04551 COVER TRAY DVDR615
138 3103 604 00811 HOLDER COVER TRAY
147 3103 604 01141 COVER DUST
148 3103 603 20122 FOAM RUBBER SEALING
150 3139 244 04541 WINDOW DVDR615
158 3139 244 04481 WINDOW LEFT DVDR615
160 3139 244 04471 DOOR FLAP DVDR615
162 3103 604 00441 HINGE DOOR FRONT AV
164 3103 601 20231 SPRING GROUND
168 3103 601 20212 SPRING I-LINK
196 3139 241 21871 COVER TOP DVDR615
274 3103 604 00622 FOOT
276 3103 603 20041 CUSHION FOOT
288 4822 532 60948 BUSH 450H259010
292 2822 031 01441 FAN 12VDC 0.7W 3000RPM
333 3139 248 72121 REMOTE CONTROL
DVDR615
336 2422 070 98231 MAIN CORD IEC 2A5 1M8
VH BK B
340 3103 308 92610 CABLE AUDIO 2X2RCA
MALE 1.5MTR
341 4822 321 61579 VIDEO-CABLE
345 4822 320 50377 CONNECT. CABLE PAL
1001 3139 248 82902 PCBAS MOBO 04 AP2
1004 9305 025 84121 VAU8041/21 MODULE
1005 3139 248 83071 PCBAS FRONT DVDR615
8003 3139 111 04001 FFC FOIL 15P/180/15P BD
1MMP
8007 3139 111 03991 FFC FOIL 22P/280/22P BD
1MMP
8008 3139 110 34891 FFC FOIL 22P/120/22P AD
1MMP
8010 3139 111 03981 FFC FOIL 10P/280/10P BD
1MMP
8011 2422 076 00578 CBLE IEEE1394 F/480/SHR
MISCELLANEOUS VAU8041
MODULE EXPLODED VIEW
Various
5 3139 194 01581 SEALING STRIP
12 3104 148 01950 SLEDGE MOTOR
90 3104 144 10730 SUSPENSION
94 3139 190 40231 T6 PAN HEAD M2X8.5 TT-P
SEMS FW
100 3139 197 50301 AV3.5 MECHANISM ASSY
(DVD-M)
101 3139 197 60291 AV3.5 LOADER ASSY
105 3139 198 80010 SEALING STRIP
120 3139 198 00620 TRAY MOTOR
121 3104 144 04980 MOTOR PULLEY, TRAY
125 3104 144 10121 TRAY MOTOR BELT
147 3104 144 04272 TRAY
150 3139 197 60301 TOP PLATE ASSY
179 3104 128 09271 FEBE PCBA 4MB/32MB NO
DV-IN DVDR610
179 3104 128 09281 FEBE PCBA 4MB/32MB W/
DV-IN DVDR615/616
190 3139 194 01541 HEAT SINK PAD
(CENTAURUS)
191 3139 194 01551 HEAT SINK PAD
(CHEETAH)
193 3139 194 01561 HEAT SINK PAD (DRIVER)
FRONT BOARD (KEY, STBY, OPCL
& 5WSW)
Various
1120 4822 276 13732 SWITCH TACT PUSH
1122 4822 276 13732 SWITCH TACT PUSH
1202 4822 276 13732 SWITCH TACT PUSH
1203 4822 276 13732 SWITCH TACT PUSH
1205 4822 276 13732 SWITCH TACT PUSH
1209 4822 276 13732 SWITCH TACT PUSH
1210 4822 276 13732 SWITCH TACT PUSH
1920 2422 026 05301 SOC CINCH V 3P FJPJ1127
B
1921 2422 026 05307 CON MDIN H 4P F YKF51 B
1922 2422 025 17797 CON V 15P F 1.00 FFC 0.3 B

3211 4822 117 12063NTC DC 5W 10K 5%

6200 9340 548 61115 SM PDZ12B
6201 9340 548 61115 SM PDZ12B
6202 9340 548 61115 SM PDZ12B
6203 9340 548 61115 SM PDZ12B
6204 9340 548 61115 SM PDZ12B
6211 9322 190 44676 LED VS LTL-1MHHR

7200 9322 185 95667IR RECEIVER TSOP4836
MOBO (ANALOG) BOARD
Various
1100 2722 171 00042 VFD DISPLAY BJ928GN
1101 4822 242 82114 CERAM RESONATOR
8MHZ
1102 4822 242 70938 RES XTAL 32,768KHZ)
1300 4822 071 51002 FUSE RAD LT 1A 250V IEC
1301 9965 000 07788 FUSE RAD T2A IEC UL250V
1302 4822 252 11215 SURGE PROTECT DSP-
301N-A21FA
1303 4822 265 11253 SOC FUSE V 1P F PTF/65 B
1304 2422 086 10786 FUSE RAD LT 4A 250V IEC
A
1305 4822 253 30383 FUSE 5X20 HT 2A5 250V
IEC B
1306 4822 071 55001 FUSE RAD LT 500MA 250V
IEC A
1308 4822 071 51002 FUSE RAD LT 1A 250V IEC
1310 2422 086 10769 FUSE RAD LT 125MA 250V
IEC A
1600 4822 242 10434 RES XTL 18MHZ432 12P
HC49/U A
1700 2422 542 90125 TUN V+U PLL IEC BGIDK B
1900 4822 265 11154 CON V 22P F 1.00 FFC 0.3 B
1914 4822 267 11031 CON V 10P F 1.00 FFC 0.3 B
1931 4822 265 20723 CON BM V 2P M 7.92 VH B
1941 2422 026 05291 SOC CINCH H 8P F
YEWHRDBU B
1942 2422 025 17797 CON V 15P F 1.00 FFC 0.3 B
1944 2422 026 05291 SOC CINCH H 8P F
YEWHRDBU B
1947 4822 265 11154 CON V 22P F 1.00 FFC 0.3 B
1948 4822 267 10994 SOC MDIN H 4P F TCS7927
B
1949 4822 267 10994 SOC MDIN H 4P F TCS7927
B
1955 4822 267 31729 SOC CINCH H 1P F BK B
2102 4822 124 11968 220MF +80-20% 5,5V
2301 2020 554 90173 CERSAF KX 250V S 2N2
PM20 B
2302 2020 021 91506 ELCAP ZL 1000UF 20% 16V
2305 4822 122 31175 1NF 10% 500V
2307 4822 122 31175 1NF 10% 500V
2308 2020 021 91506 ELCAP ZL 1000UF 20% 16V
2310 4822 121 10512 275V 220N 20%
2312 4822 121 70386 47NF 10% 250V
2314 2022 020 00742 ELCAP LS 400V S 68U
PM20 B
2316 2020 021 91506 ELCAP ZL 1000UF 20% 16V
2319 4822 126 14525 47PF 5% 1KV
2322 2020 021 91506 ELCAP ZL 1000UF 20% 16V
2325 4822 121 41857 10NF 5% 250V
2327 4822 126 10206 2,2NF 10% NP0 500V
2328 4822 121 51598 2,2NF 5% 400V
3124 4822 052 10109 10R 5% 0,33W
3300 4822 053 21335 3M3 5% 0,5W
3301 4822 053 21335 3M3 5% 0,5W
3316 4822 116 83872 220R 5% 0,5W
3319 4822 053 21684 680K 5% 0,5W
3330 2322 193 14477 RST MFLM PR01 A 0R47
PM5 A
3331 2322 193 14687 RST MFLM PR01 A 0R68
PM5
5100 2422 549 43062 IND FXD SM EMI 100MHZ
600R R
5101 4822 157 50964 100MUH
5300 2422 531 02546 TFM SMT SLOT
SRW28EC9-E01V0* B
5301 2422 535 94634 IND FXD LHL08 S 2U2 PM20
A
5303 2422 549 44509 FIL MAINS 25MH 0A4
HF2022R Y
5304 4822 157 11737 22UH 10% 9X9,5
5305 4822 157 11737 22UH 10% 9X9,5
5306 4822 157 70826 2,4UH
5307 4822 157 11737 22UH 10% 9X9,5
5308 4822 157 70826 2,4UH
5400 4822 157 11706 10UH 5% 2,4X3,4
5401 4822 157 11706 10UH 5% 2,4X3,4
5402 4822 157 11706 10UH 5% 2,4X3,4
5551 2422 536 00019 TRANSFORMER 6RG
(SAGA) B
5600 4822 157 11706 10UH 5% 2,4X3,4
5601 4822 157 11706 10UH 5% 2,4X3,4
5700 4822 157 11139 6,8UH 5%
5701 4822 157 11706 10UH 5% 2,4X3,4
5702 4822 157 11139 6,8UH 5%
5703 2422 549 43062 IND FXD SM EMI 100MHZ
600R R
5704 2422 549 43062 IND FXD SM EMI 100MHZ
600R R

6001 4822 130 11397 BAS316
6002 4822 130 11397 BAS316
6003 4822 130 11397 BAS316
6100 4822 130 80622 BAT54
6101 4822 130 80622 BAT54
6102 4822 130 11416 PDZ6.8B
6103 4822 130 11397 BAS316
6104 4822 130 11397 BAS316
6109 4822 130 11397 BAS316
6255 9322 175 41687 SOC FIB OPT JFJ1000 L
6300 9322 161 76682 SB340L-7024
6301 9322 161 76682 SB340L-7024
6302 4822 130 31083 BYW55
6303 4822 130 31083 BYW55
6304 9322 184 68682 STPS5L40-C2
6305 4822 130 31083 BYW55
6306 9322 184 68682 STPS5L40-C2
6307 4822 130 31083 BYW55
6308 9322 126 71673 BYT42M A
6309 9322 161 78682 SB360L-7024
6310 4822 130 31878 1N4003G
6311 4822 130 10871 SBYV27-200
6312 4822 130 11397 BAS316
6313 4822 130 11416 PDZ6.8B
6314 3198 020 55680 SM BZX384-C5V6
6315 9322 206 47683 1N4935
6316 4822 130 34142 BZX79-B33
6317 4822 130 80622 BAT54
6318 9322 206 47683 1N4935
6319 4822 130 30842 BAV21
6320 9340 548 69115 SM PDZ27B
6321 4822 130 34382 BZX79-B8V2
6322 4822 130 11397 BAS316
6400 9340 548 61115 SM PDZ12B
6401 9340 548 61115 SM PDZ12B
6402 9340 548 61115 SM PDZ12B
6403 9340 548 61115 SM PDZ12B
6404 9340 548 61115 SM PDZ12B
6405 9340 548 61115 SM PDZ12B
6406 9340 548 61115 SM PDZ12B
6407 9340 548 61115 SM PDZ12B
6408 9340 548 61115 SM PDZ12B
6409 9340 548 61115 SM PDZ12B
6410 9340 548 61115 SM PDZ12B
6411 9340 548 61115 SM PDZ12B
6412 9340 548 61115 SM PDZ12B
6413 9340 548 61115 SM PDZ12B
6500 9340 548 61115 SM PDZ12B
