Philips DVDR615 - Page 169

Spare Parts List
EN 169DVDR615/69 10.
6501 9340 548 61115 SM PDZ12B
6502 9340 548 61115 SM PDZ12B
6503 9340 548 61115 SM PDZ12B
6600 4822 130 11397 BAS316

7001 9352 668 47118 UDA1334BTS/N2
7002 4822 130 60854 DTA124EU-W
7003 4822 209 32071 MC33079D
7004 4822 130 60854 DTA124EU-W
7006 9352 670 99118 UDA1361TS/N1
7007 4822 130 61553 DTC124EU
7100 9322 196 98685 NCP301LSN47
7101 4822 130 61553 DTC124EU
7102 4822 130 40981 BC337-25
7103 3198 010 42310 BC847BW
7104 4822 130 41246 BC327-25
7105 4822 130 41246 BC327-25
7106 3198 010 42310 BC847BW
7107 3139 240 50921 TMP87CM74AF-5JP4 w/
mark ASP017-50921 (non
Lead-free)
7109 3198 010 42310 BC847BW
7110 4822 130 61553 DTC124EU
7111 3198 010 42310 BC847BW
7112 9965 000 04199 BSN20
7113 3198 010 42320 BC857BW
7114 9965 000 04199 BSN20
7115 3198 010 42310 BC847BW
7117 3198 010 42320 BC857BW
7118 3198 010 42320 BC857BW
7119 3198 010 42310 BC847BW
7300 9322 183 38668 SM STS9NF30L
7301 4822 209 14933 TL431IZ
7302 4822 130 11336 STP16NF06FP
7303 4822 209 14933 TL431IZ
7304 9322 183 38668 SM STS9NF30L
7305 4822 209 14933 TL431IZ
7306 9322 163 75685 SM SI2306DS
7307 4822 130 61553 DTC124EU
7308 4822 130 11417 STP3NB60FP
7309 9322 180 12685 SM SI2312DS
7310 4822 130 41782 BF422
7311 9352 673 56112 TEA1507P/N1
7312 3198 010 42320 BC857BW
7313 3198 010 42310 BC847BW
7314 3198 010 42310 BC847BW
7316 9965 000 09548 PHOTOCOUPLER
TCET1108G
7318 4822 130 40959 BC547B
7319 4822 209 14933 TL431IZ
7321 9322 163 75685 SM SI2306DS
7322 9322 163 75685 SM SI2306DS
7323 3198 010 42310 BC847BW
7324 4822 130 61553 DTC124EU
7325 9322 163 75685 SM SI2306DS
7400 3198 010 42320 BC857BW
7401 9322 179 71668 NJM2285M
7402 9322 173 41668 STV6618
7403 3198 010 42310 BC847BW
7404 3198 010 42310 BC847BW
7500 4822 209 62312 MC33078D
7501 5322 209 11102 HEF4052BT
7503 9340 219 30115 BC817-25W
7504 9340 219 30115 BC817-25W
7551 5322 209 11517 PC74HCU04T
7600 9322 186 87668 SM MSP3415G-QG-B8V3
7700 3198 010 42320 BC857BW
FEBE BOARD
Various
1000 2422 025 17955 CON V 6P M 1.00 SR R
1001 2422 543 01368 RES XTL 24M576 12P
CX8045 R
1002 2422 543 01422 RES XTL 24M576 18P
CX8045 R
1100 2422 025 17821 CON H 45P F 0.50 FPC 0.3 R
1302 2422 543 01025 RES XTL 16M93 20P CX-
16F R
1400 2422 025 05548 CON H 4P F 1.00 FFC 0.3
1401 2422 025 18382 CON H 11P F 1.00 FPC 0.3
1601 2122 662 00152 PTC 1812 16V 0R18 PM
1602 2122 662 00136 PTC 1812 6V 0R21 PM
1901 2422 025 16389 CON BM V 22P F 1.00 FFC
0.3 R
1902 2422 025 16389 CON BM V 22P F 1.00 FFC
0.3 R
1903 8204 056 66001 CON V 7P M 2.00 PH R
1904
 2422 086 11087 FUSE F 1A 125V UL R
1905 8204 056 66011 CON V 12P M 2.00 PH R
1906
 2422 086 11087 FUSE F 1A 125V UL R
1907 2422 025 16729 CON BM V 10P F 1.00 FFC
0.3 R
1908
 2422 086 11087 FUSE F 1A 125V UL R

2013 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2014 4822 124 12095 100UF 20% 16V
2062 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2071 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2073 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2081 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2083 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2098 4822 124 80151 47UF 16V
2107 5322 124 41945 22UF20% 35V
2416 4822 124 12095 100UF 20% 16V
2431 4822 124 23002 10UF 16V
2446 5322 124 41945 22UF20% 35V
2448 2020 552 95812 CER2 1206 X7R 16V 1U
PM10 R
2515 4822 124 23002 10UF 16V
2533 4822 124 23002 10UF 16V
2538 4822 124 23002 10UF 16V
2580 5322 124 41945 22UF20% 35V
2612 5322 124 41945 22UF20% 35V
2653 5322 124 41945 22UF20% 35V
2654 5322 124 41945 22UF20% 35V
2666 4822 124 23002 10UF 16V
2667 4822 124 23002 10UF 16V
2668 4822 124 23002 10UF 16V
2669 4822 124 23002 10UF 16V
2812 4822 124 23002 10UF 16V
2818 4822 124 23002 10UF 16V
2828 4822 124 23002 10UF 16V
2838 2020 021 91857 ELCAP FK 6V3 100U PM20
R
2981 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2989 2020 021 91729 ELCAP RKV 35V 4U7 PM20
R
2999 2020 021 91857 ELCAP FK 6V3 100U PM20
R

3000 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3001 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3003 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3004 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3005 4822 117 13523 220R 5% RESN 0.63W
3006 4822 117 13523 220R 5% RESN 0.63W
3007 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3008 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3009 4822 117 13523 220R 5% RESN 0.63W
3010 4822 117 13523 220R 5% RESN 0.63W
3025 4822 117 12662 10R X4 5%
3029 4822 117 12662 10R X4 5%
3084 3198 031 11010 RST NETW 1206 4X100R
PM5 COL R
3085 3198 031 11010 RST NETW 1206 4X100R
PM5 COL R
3541 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3542 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3543 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3562 4822 117 13526 150R 5% RESN 0.63W
3583 4822 117 13526 150R 5% RESN 0.63W
3584 4822 117 13526 150R 5% RESN 0.63W
3585 4822 117 13526 150R 5% RESN 0.63W
3587 4822 117 13526 150R 5% RESN 0.63W
3588 4822 117 13526 150R 5% RESN 0.63W
3589 4822 117 13526 150R 5% RESN 0.63W
3615 2350 035 10829 RST NETW ARV24 4X 82R
PM5 R
3631 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3635 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3639 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3643 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3800 2350 035 10229 RST NETW ARV24 4X22R
PM5 R
3801 2350 035 10229 RST NETW ARV24 4X22R
PM5 R
3802 2350 035 10229 RST NETW ARV24 4X22R
PM5 R
3803 2350 035 10229 RST NETW ARV24 4X22R
PM5 R
3804 4822 117 13573 NETW 4 X 47R 5% MNR14
3805 4822 117 13573 NETW 4 X 47R 5% MNR14
3806 4822 117 13573 NETW 4 X 47R 5% MNR14
3807 4822 117 13573 NETW 4 X 47R 5% MNR14
3808 4822 117 13573 NETW 4 X 47R 5% MNR14
3809 4822 117 13573 NETW 4 X 47R 5% MNR14
3810 4822 117 13573 NETW 4 X 47R 5% MNR14
3811 4822 117 13573 NETW 4 X 47R 5% MNR14
3812 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3813 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3814 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3815 3198 031 13390 RST NETW 1206 4X 33R
PM5 COL
3846 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3873 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3874 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3875 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3876 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3877 3198 031 14720 RST NETW 1206 4X4K7
PM5 COL R
3897 3198 031 11030 RST NETW 1206 4X 10K
PM5 COL R
3903 3198 031 11030 RST NETW 1206 4X 10K
PM5 COL R
3904 3198 031 11030 RST NETW 1206 4X 10K
PM5 COL R

5000 4822 157 11499 BLM11P600SPT
5001 4822 157 11499 BLM11P600SPT
5002 4822 157 11499 BLM11P600SPT
5003 4822 157 11499 BLM11P600SPT
5012 4822 157 11499 BLM11P600SPT
5013 4822 157 11499 BLM11P600SPT
5016 4822 157 11499 BLM11P600SPT
5018 4822 157 11499 BLM11P600SPT
5019 4822 157 11499 BLM11P600SPT
5022 4822 157 11499 BLM11P600SPT
5101 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5102 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5103 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5104 3198 018 51090 FXDIND 0603 10U PM10
COL R
5202 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5300 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5301 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5400 2422 536 00501 IND FXD D62LCB 10U PM20
R
5405 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5501 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5502 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5504 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5603 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
5607 2422 549 45322 IND FXD 0603 EMI 100MHZ
150R R
5614 2422 549 44991 IND FXD 0603 EMI 100MHZ
600R
