Philips DVDR615 - Page 27

Diagnostic Software
EN 27DVDR615/69 5.
Table 5-1
Available channels for input of the 7118 and their description
Table 5-2 Available channels for input of the 7115 and their description
Digital Video Input Output (DVIO)
Example DS:> 603
060300:
Test OK @
Nucleus Name DS_VIP_SelectInput
Nucleus Number 604
Description Select an input video path to be switched to the analogue output pin (AOUT) of the VIP
Technical - Check the user input
- Initialise IIC
- Read out the VIP id
- Write the set of registers required for the input specified
Execution Time Less than 1 second
User Input The input to select, see table below.
Error Number Description
60400 Selecting the input of the VIP succeeded
60401 The user provided wrong input
60402 The VIP was not accessible
60402 An unsupported VIP was found
Example DS:> 604 1
060400:
Test OK @
Channel number Description
1 CVBS_Y_IN_A
2 CVBS_OUT_B
3 CVBS_Y_IN_B
4 CVBS_Y_IN_C
6C_IN
8G_IN
9Y_IN
13 B_IN
14 U_IN
18 R_IN
19 V_IN
Channel number Description
1 CVBS_Y_IN_B
2 CVBS_OUT_B_VIP
4C_IN_VIP
7 CVBS_Y_IN_B
Nucleus Name DS_DVIO_LinkDevTypeGet
Nucleus Number 700
Description Get the device (revision) type information of the 1394 Link layer IC
Technical - Initialise the PIO pins on the Codec
- Read out the ID register
Execution Time Less than 1 second
User Input None
Error Number Description
70000 Getting the information from the link layer IC succeeded
70001 Getting the information from the link layer IC failed
70002 Type not according to type stored in HW diversity string
Example DS:> 700
070000: Device type of the link layer IC: ffc00301
Test OK @
Nucleus Name DS_DVIO_PhyDevTypeGet
Nucleus Number 701
