Diagnostic Software
EN 29DVDR615/69 5.
Progressive Scan (PSCAN)
Error Number Description
70400 Routing the signals succeeded
70401 The 1394 link chip could not be initialised properly
70402 There was a syntax error in the DV stream
70403 DMA could not copy DV stream to memory. Stream connect-
ed?
70404 DMA not working properly
Example DS:> 704
070400:
Test OK @
Nucleus Name DS_DVIO_DetectNode
Nucleus Number 705
Description Check whether a DV node can be detected by the hardware. This test works for both NTSC
and PAL.
Technical - Initialise the 1394 interface
- Detect whether a node is in range
Execution Time 3 or 5 seconds (3 when OK, 5 when no stream or error)
User Input None
Error Number Description
70500 The node was detected OK
70501 The 1394 link chip could not be initialised properly
70502 Unable to write to 1394 PHY chip
70503 Unable to read from 1394 PHY chip
70504 No node was detected
Example DS:> 705
070500:
Test OK @
Nucleus Name DS_DVIO_DetectStream
Nucleus Number 706
Description Check whether a DV stream can be detected by the hardware. This test works for both
NTSC and PAL.
Technical - Initialise the 1394 interface
- Start receiving the stream
- Detect whether the stream is OK
Execution Time 3 or 5 seconds (3 when OK, 5 when no stream or error)
User Input None
Error Number Description
70600 The stream was detected
70601 The 1394 link chip could not be initialised properly
70602 No stream detected
Example DS:> 706
070600:
Test OK @
Nucleus Name DS_PSCAN_DencDevTypeGet
Nucleus Number 800
Description Retrieve the device type information from the progressive scan DENC IC
Technical -
Execution Time Less than 1 second
User Input None
Error Number Description
80000 Retrieving the device type information succeeded
80001 The IIC bus was not accessible
80002 There was a timeout reading the device
80003 The IIC acknowledge was not received
80004 Communicating with the progressive scan DENC-IC failed
80005 The initialisation of the IIC bus failed
Example DS:> 800
080000: Device Type xxxx t.b.d.
Test OK @
