Diagnostic Software
EN 35DVDR615/69 5.
Error Number Description
90600 The command executed successfully
90601 This nucleus cannot be executed because the Self-Test failed
90602 The BE cannot enter normal operating mode
90603 Unable to send the tray in
90604 Unable to read TOC from disc
90605 Invalid disc is loaded, please insert a DVD+RW disc
90606 Writing the test pattern to DVD+RW failed
90607 Reading back the test pattern from DVD+RW failed
90608 Compare check failed
90609 Calibrating DVD+RW failed
Example DS:> 906
090600: Testing on sector 0x5dbe0: OK
Test OK @
Nucleus Name DS_BE_WriteReadDvdR
Nucleus Number 907
Description Write data to and read data from a DVD+R disc through the basic engine for verification of
the writing
Technical - Check if an AV2 or AV3 is connected
- Execute DS_BE_GetSelftestResults
- Send the TRAY_IN command
- Send the READ_TOC command
- Use the OPC area to test if the DVD+R is (still) writable
- Generate test data to write to the DVD+R
- In case of an AV2 Transfer the test data to the disc location using DMA
- In case of an AV3 Transfer the test data to the disc location using PIO mode ATAPI
WRITE_10
- In case of an AV2 Read back the data from disc using DMA
- In case of an AV3 Transfer the test data to the disc location using PIO mode ATAPI
READ_10
- Compare the two data areas and check whether the areas are equal
Execution Time Approximately 20 seconds
User Input None
Error Number Description
90700 The command executed successfully
90701 This nucleus cannot be executed because the Self-Test failed
90702 The BE cannot enter normal operating mode
90703 Unable to send the tray in
90704 Unable to read TOC from disc
90705 Invalid disc is loaded, please insert a DVD+RW disc
90706 Unable to write, the DVD+R disc is full
90707 No writable DVD+R sector found
90708 Writing the test pattern to DVD failed
90709 Reading back the test pattern from DVD failed
90710 Compare check failed
Example DS:> 907
090700: Testing on sector 0x36210: OK
Test OK @
Nucleus Name DS_BE_StatisticalInformationGet
Nucleus Number 908
Description Retrieve the statistical information from the basic engine
Technical - Check if an AV2 or AV3 is connected
- In case of an AV2 Send the S2B GET_STATISTICAL_INFO command
- In case of an AV3 Send the transparent BIT engine GET_STATISTICAL_INFO
command
- Display the info returned from the BE
Execution Time Less than 1 second on AV2
2 seconds on AV3
User Input None
