Philips DVDR615 - Page 48

Diagnostic Software
EN 48 DVDR615/695.
121202 Reading the data from the UART failed
Example DS:> 1212 2
121200: The HEX value that was read is: 0x50 0xD1 0x00
Test OK @
Nucleus Name DS_SYS_VideoLoopThroughStart
Nucleus Number 1213
Description The video signal, which is conform the user input, is routed from the input to the output.
The input is set using the proper nucleus to route the signal on the board(s). All outputs
are enabled.
Technical - Decode the videosignal: PAL / NTSC and Y/C, RGB, CVBS,YUV
- Initialise the Video Input Processor and check for valid signal
- Initialise the Video Front End and start capturing frames to memory
- Initialise the SYNC module
- Initialise the Video Post Processing and retrieve frames from memory
- Initialise the mixer
- Initialise the DENC module
- Route the signal to all outputs
Execution Time Less than 1 second, but stays running.
User Input <vipInput> <VideoOutput> <VideoStandard>
1. vipInput (CVBS, YC, YUV, RGB, 1 to 9(see table below)).
LECO Premier specific
User input Video input Data path to VIP
1 RGB SCART aux RGB in
2 YC SCART aux Y/C in
3 CVBS SCART aux CVBS
4 CVBS Tuner
5 YC Front Y/C
6 CVBS Front CVBS
7 CVBS SCART TV CVBS
8 YC CE mode Y/C in
9 CVBS CE mode CVBS in
10 XPORT XPORT
2. VideoOutput (YUV, RGB).
3. VideoStandard (PAL, NTSC).
Error Number Description
121300 Video LoopthroughStart succeeded
121301 User input is not valid.
121302 Initialisation of the VIP failed.
121303 Unable to stop the loop through before restarting.
121304 Video Signal on the input is not a valid signal.
121305 Initialisation of the VFE failed.
121306 The digital board hardware information is corrupt
Example DS:> 1213 CVBS RGB PAL
121300:
Test OK @
Nucleus Name DS_SYS_VideoLoopThroughStop
Nucleus Number 1214
Description Stop routing the video input to all the outputs.
Technical Stop the DENC and the Video Front End
Execution Time Less than 1 second.
User Input -
Error Number Description
121400 VideoLoopthroughStop succeeded
121401 DENC module on Codec failed.
Example DS:> 1214
121400:
Test OK @
Nucleus Name DS_SYS_VideoLoop
Nucleus Number 1215
