Philips DVDR615 - Page 62

Diagnostic Software
EN 62 DVDR615/695.
Technical - Initialise the display.
- Display the key pressed by the user on the display.
- Monitor the service port for an abort and get the next key pressed.
- Update the display and repeat previous steps until user stops / confirms.
- Display the number of keys that were pressed.
Execution Time Depends on the user.
User Input None
Error Number Description
161200 Checking all keys succeeded
161201 IIC-bus communication failed
161202 The user signals a failure of the keyboard
161203 The user aborted the test
Example DS:> 1612
161200:
Test OK @
Nucleus Name DS_ASP_RemoteControl
Nucleus Number 1613
Description This nucleus checks the interface to the remote control by having the user confirm the
key-code displayed. At least one key must be tested. If the user presses a or A the test
is aborted. If the user presses o or O the test is indicated as OK. If the user holds down
PLAY for more than a second the test is indicated as OK, if the user holds down
RECORD the test is indicated as failed.
Technical - Initialise the display.
- Display the key pressed by the user on the display.
- Monitor the service port for an abort and get the next key pressed.
- Update the display and repeat previous steps until user stops / confirms.
- Display the number of keys that were pressed.
Execution Time Depends on the user.
User Input None
Error Number Description
161300 The test succeeded
161301 IIC-bus communication failed
161302 The user signals a failure of the remote control
161303 The user aborted the test
Example DS:> 1613
161300:
Test OK @
Nucleus Name DS_ASP_LEDsOn
Nucleus Number 1614
Description This nucleus switches on the RECORD, TRAY, and EPG-LED, when available
Technical - Check if the analogue board is a MOBO board, if so:
- Read the ASP pio port.
- Set the RECORD-LED bit on in this port.
- Write the ASP pio port.
- Read the ASP pio port.
- Set the TRAY-LED bit on in this port.
- Write the ASP pio port.
- Read the ASP pio port.
- Set the EPG-LED bit on in this port.
- Write the ASP pio port.
-Else
- Set the RECORD-LED bit on.
- Write the external ASP pio port.
- Set the TRAY-LED bit on.
- Write the external ASP pio port.
- Set the EPG-LED bit on.
- Write the external ASP pio port.
Execution Time Less than 1 second.
User Input None
Error Number Description
161400 Switching on the LEDs succeeded
161401 IIC-bus communication failed
Example DS:> 1614
161400:
Test OK @
