Diagnostic Software
EN 61DVDR615/69 5.
160801 IIC-bus communication failed
Example DS:> 1608
160800:
Test OK @
Nucleus Name DS_ASP_BlinkDisplay
Nucleus Number 1609
Description This nucleus lights the entire display, and lets it blink.
Technical - Set all segments on in the blink buffer.
- Set the grids correct in the blink buffer.
- Send the blink buffer to the ASP.
Execution Time Less than 1 second.
User Input None or on to start the blinking of the display. off To stop the blinking of the display.
Error Number Description
160900 The test succeeded
160901 IIC-bus communication failed
160902 The user provided wrong input
Example DS:> 1609
160900:
Test OK @
DS:> 1609 off
160900:
Test OK @
Nucleus Name DS_ASP_DimmingDisplay
Nucleus Number 1610
Description This nucleus lights the entire display, and dims it.
Technical Change in a loop the display brightness from maximum to minimum.
Execution Time Less than 1 second.
User Input ON or OFF
Error Number Description
161000 The test succeeded
161001 IIC-bus communication failed
161002 The user provided wrong input
Example DS:> 1610 ON
161000:
Test OK @
Nucleus Name DS_ASP_ClearDisplay
Nucleus Number 1611
Description This nucleus clears the display and deactivates dimming/blinking functionality
Technical - Make the display buffer empty.
- Make the blink buffer empty.
- Send the display buffer to the ASP.
- Send the blink buffer to the ASP.
Execution Time Less than 1 second.
User Input None
Error Number Description
161100 The test succeeded
161101 IIC-bus communication failed
Example DS:> 1611
161100:
Test OK @
Nucleus Name DS_ASP_KeyBoard
Nucleus Number 1612
Description This nucleus checks all keys of the keyboard by having the user confirm the key-code
displayed of all keys. If the user presses a or A the test is aborted. If the user presses
o or O the test is indicated as OK. If the user holds down PLAY for more than a second
the test is indicated as OK, if the user holds down RECORD the test is indicated as
failed.
