Philips DVDR615 - Page 60

Diagnostic Software
EN 60 DVDR615/695.
Technical T.B.D. !!
Execution Time Less than 1 second.
User Input none
Error Number Description
160400 Setting the correction values succeeded
Example DS:> 1604
160400: T.B.D. !!
Test OK @
Nucleus Name DS_ASP_RealTimeClockAdjustment
Nucleus Number 1605
Description This nucleus sets a test signal for clock crystal measurement. The signal with a
frequency of 1 kHz and duty cycle of 50% appears on pin RCC.
Technical Send Clock Adjustment command to the ASP.
Execution Time Less than 1 second.
User Input None
Error Number Description
160500 The test succeeded
160501 The ASP initialisation failed.
160502 The IIC bus failed.
Example DS:> 1605
160500:
Test OK @
Nucleus Name DS_ASP_NTCGet
Nucleus Number 1606
Description This nucleus reads the value of the NTC-resistor connected to the ASP, which tells the
ambient temperature to the processor.
Technical - Read the ADC input pin of the ASP that is connected to the NTC-resistor.
- Display this value.
Execution Time Less than 1 second.
User Input None
Error Number Description
160600 Getting the NTC-value succeeded
160601 The IIC bus failed
Example DS:> 1606
160600: Temperature(NTC) ADC input value = 0x94
Test OK @
Nucleus Name DS_ASP_FanSpeedSet
Nucleus Number 1607
Description This nucleus sets the speed of the fan that controls the temperature within the set.
Technical - Decode user input.
- Set pio-pins FAN_C1 and FAN_C2.
Execution Time Less than 1 second.
User Input Speed to be set: off, low, medium, high
Error Number Description
160700 Setting the new fan speed succeeded
160701 The IIC bus failed
160702 The user provided wrong input
Example DS:> 1607 low
160700:
Test OK @
Nucleus Name DS_ASP_LightDisplay
Nucleus Number 1608
Description This nucleus lights the entire display.
Technical - Set all segments on in the display buffer.
- Set the grids correct in the display buffer.
- Send the display buffer to the ASP.
Execution Time Less than 1 second.
User Input None
Error Number Description
160800 Lighting the entire display succeeded
