Philips DVDR615 - Page 59

Diagnostic Software
EN 59DVDR615/69 5.
160006 The IIC bus initialisation failed
Example DS:> 1600
160000:
Test OK @
Nucleus Name DS_ASP_Version
Nucleus Number 1601
Description This nucleus returns the version number of the software running on the ASP and if
available that of the display driver.
Technical Read versions from ASP and display it.
Execution Time Less than 1 second.
User Input None
Error Number Description
160100 Retrieving the software versions succeeded
160101 The IIC bus initialisation failed.
160102 The IIC bus failed.
160103 The CRC checksum of the message is wrong.
Example DS:> 1601
160100:
Software version : 0.9
Display driver version: 0.1
Hardware version : 0x02
Hardware layout : 0x03
Hardware revision : 0x00
Test OK @
Nucleus Name DS_ASP_RealTimeClockSetValues
Nucleus Number 1602
Description This nucleus is used to set the real time clock to the correct values.
Technical - Decode the user input.
- Write RTC value to ASP.
Execution Time Less than 1 second.
User Input User must give time and date like this: hh:mm:ss dd/mm/yy
Error Number Description
160200 Setting the real time clock succeeded
160201 The ASP initialisation failed.
160202 The IIC bus failed.
160203 Wrong user input.
Example DS:> 1602 03:20:01 22/06/03
160200:
Test OK @
Nucleus Name DS_ASP_RealTimeClockGetValues
Nucleus Number 1603
Description This nucleus is used to retrieve the actual real time from the ASP
Technical - Read RTC value from ASP.
- Decode the RTC value.
Execution Time Less than 1 second.
User Input None
Error Number Description
160300 Retrieving the real time succeeded
160301 The ASP initialisation failed.
160302 The IIC bus failed.
160303 The CRC checksum of the message is wrong.
160304 The Real Time Clock has been found invalid and thus set
to default values.
Example DS:> 1603
Time: 03:20:17
Date: 22/06/03 (dd/mm/yy)
160300:
Test OK @
Nucleus Name DS_ASP_RealTimeClockSetCorrection
Nucleus Number 1604
Description This nucleus sets the correction value needed for the real time clock
