EN 58 DVDR615/695.
Electronic Program Guide Board (EPGB)
ANALOGUE SLAVE PROCESSOR (ASP)
User Input The user inputs 6 parameters:
<UartNr><baudrate><flowcontrol><databits><parity><stopbits>
UartNr:
1=UART port 1 : not used (Chrysalis only)
2=UART port 2 : Bit Engine or DTTM (Chrysalis only)
3=UART port 3 : Analogue board
baudrate:
115200,62500,57600,38400,19200,9600,4800,2400,1200
flowcontrol:
0=disabled 1=enabled
databits:
7 or 8
parity:
“NO”, “ODD” or “EVEN”
stopbits:
1 or 2
Error Number Description
123600 Setting up the selected UART succeeded
123601 User provided Invalid setup parameters
123602 Setting up the selected UART Failed
123603 Selected UART is not available
Example (Chrysalis) DS:> 1236 2 38400 0 8 NO 1
123600:
Test OK @
Example (Leco) DS:> 1236 2 38400 0 8 NO 1
123603: The selected UART is not available
Error @
Nucleus Name DS_EPGB_VersionGet
Nucleus Number 1300
Description Returns the version of the EPG board.
Technical - Issue the command to get the version of the EPG board to the analogue board
- Return the received information to the user
Execution Time 3 seconds.
User Input None
Error Number Description
130000 Getting the version succeeded
130001 Communication with the analog board failed.
130002 Communication with the EPG board failed.
130003 There was no response from the analogue board.
130004 No DS error code known for analogue board error.
Example DS:> 1300
130000:
Version : 6.1.9
Test OK @
Nucleus Name DS_ASP_Communication
Nucleus Number 1600
Description This nucleus checks the communication between the IIC controller of the Codec and
the ASP.
Technical - Initialise IIC-bus.
- Read something from ASP.
- Handle the errorcode.
Execution Time Less than 1 second.
User Input None
Error Number Description
160000 Communicating with the ASP succeeded
160001 The IIC bus was not accessible
160002 There was a timeout reading the device
160003 The IIC acknowledge was not received
160004 An IIC-bus error occurred
160005 Got unknown IIC bus error
