6-1
MECHANICAL & ACCESSORIES PARTS LIST
SET & PACKAGING PARTS (FOR PAGES 2-2 TO 2-3)
A00 9965 000 25549 VCR MECHANISM
A26 9965 000 25550 DVD MODULE
A43 9965 000 25539 PANEL ASSEMBLY, FRONT /00
A43 9965 000 25668 PANEL ASSEMBLY, FRONT /02/14
A43 9965 000 25526 PANEL ASSEMBLY, FRONT /05
A46 9965 000 25548 MAIN BOARD ASSEMBLY /00
A46 9965 000 25669 MAIN BOARD ASSEMBLY /02
A46 9965 000 25674 MAIN BOARD ASSEMBLY /05
A46 9965 000 25675 MAIN BOARD ASSEMBLY /14
A47 9965 000 25547 POWER SUPPLY BOARD ASSEMBLY
323 9965 000 25560 CASE ASSEMBLY
261A 9965 000 25545 RUBBER, FOOT
265 9965 000 25546 HOLDER, POWER CORD
283 9965 000 25540 DOOR, VCR
284 4822 492 42785 SPRING DOOR
285 9965 000 25541 DOOR, DVD
286 9965 000 25542 SPRING, DVD
300 9965 000 25538
!
POWER CORD W/CONN. /00/02/14
300 9965 000 25525
!
POWER CORD W/CONN. /05
806 9965 000 25543 RF PAL DOUBLE SHIELD
821 9965 000 25544 SCART TO SCART 21 PIN
900 9965 000 18509 REMOTE CONTROLLER ASSEMBLY
VCR MECHANISM PARTS (FOR PAGES 4-28 TO 4-30)
A01 9965 000 25617 DRUM(CIRC) ASSEMBLY, D37-6CH PAL
A03 9965 000 25618 ARM ASSEMBLY, CLEANER - D37
A11 9965 000 25619 GEAR ASSEMBLY, P3 - D37
A12 9965 000 25620 GEAR ASSEMBLY, P2 - D37
A21 9965 000 25621 HOLDER ASSEMBLY, CST - D37
A22 9965 000 25622 GEAR ASSEMBLY, RACK F/L - D37
A23 9965 000 25623 ARM ASSEMBLY, F/L - D37
A24 9965 000 25624 LEVER ASSEMBLY, SWITCH(C) - D37
003 9965 000 25625 HOLDER, FPCB(6CH) - D37C MO
004 9965 000 25626 CAP, FPCB - D37C MOLD
008 9965 000 25627 CABLE, FLAT 7PIN 17CM
009 9965 000 25628 ARM, T/UP OTHER - D37
011 9965 000 25629 ARM ASSEMBLY, TENSION - D37
012 9965 000 25630 BASE ASSEMBLY, P2 -D37
013 9965 000 25631 BASE ASSEMBLY, P3 - D37
014 9965 000 25632 BASE ASSEMBLY, P4 - D37
015 9965 000 25633 OPENER, LID OTHER - D37
016 9965 000 25634 BASE ASSEMBLY, A/C HEAD (ALPS)
017 9965 000 25635 REEL, S OTHER - D37
021 9965 000 25636 BRAKE ASSEMBLY, T - D37
022 9965 000 25637 HEAD(CIRC), ST FE HEAD FOR D37
023 9965 000 25638 BASE, LOADING OTHER - D37
024 9965 000 25639 ARM ASSEMBLY, IDLER(H)
026 9965 000 25640 MOTOR ASSEMBLY, L/D - (DI) D37
027 9965 000 25641 GEAR, WHEEL OTHER - D37
028 9965 000 25642 REEL, T OTHER - D37
029 9965 000 25643 ARM ASSEMBLY, PINCH - D37
031 9965 000 25644 SPRING, COIL TENSION - D37
051 9965 000 19315 CAPSTAN
052 9965 000 25645 MOTOR, CAPSTAN F2QVB66 SANKYO
052A 9965 000 25660 SUPPORTER, CAPSTAN OTHER - D37
055 9965 000 25646 GEAR, DRIVE OTHER - D37
056 9965 000 25647 GEAR, CAM OTHER - D37
058 9965 000 25648 BRAKE ASSEMBLY, CAPSTAN -D37
060 9965 000 25649 LEVER, F/R OTHER - D37
061 9965 000 25650 CLUTCH ASSEMBLY, D37(M)
064 9965 000 25651 GEAR, SECTOR OTHER - D37
076 9965 000 25652 LEVER, SPRING OTHER - D37
077 9965 000 25653 PLATE, SLIDER OTHER - D37
078 9965 000 25654 LEVER, TENSION OTHER - D37
079 9965 000 25655 BASE, TENSION OTHER - D37
080 9965 000 25656 LEVER, BRAKE OTHER - D37
100 9965 000 25657 PLATE ASSEMBLY, TOP - D37
109 9965 000 25658 OPENER, DOOR OTHER - D37
405 9965 000 25659 SCREW, PAN HEAD M3.0 L4.0
406 4822 502 21655 SCREW, PAN HEAD M3.0 L6.0
409 9965 000 19341 D2.6 L5.0 SWRCH18A/FZY TAP
410 9965 000 19342 D2.6 L6.8 MSWR3/FZY
517 9965 000 13164 WASHER STOPPER
518 9965 000 13163 WASHER STOPPER
DVD MODULE PARTS (FOR PAGES 5-5 TO 5-6)
A01 9965 000 18546 CLAMP ASSEMBLY, DISC DP-7 (DI)
A02 9965 000 25661 LOADER ASSEMBLY
A03 9965 000 25662 DVD-M DRIVE ASSEMBLY
010 9965 000 25663 CABLE, FLAT 11PIN 12CM
011A 9965 000 25667 CABLE, FLAT 23PIN 20CM
012 9965 000 25664 RUBBER, DAMPER DP7
012 9965 000 18520 RUBBER, DAMPER DP7 (ALTERNATIVE)
013 9965 000 18521 BELT, TRAY MOTOR
015 9965 000 25665 PWB (PCB) ASSEMBLY,MOTOR TRAY
026 9965 000 25666 TRAY, DVD DISC
Note: Only the parts mentioned in this list are normal service spare parts.
