ELECTRICAL PARTS LIST
6-2
POWER SUPPLY BOARD ASSEMBLY
MISCELLANEOUS
F101 4822 070 31602
!
FUSE 1600MA 250 V 5.2X20
T101 9965 000 25558
!
TRANSFORMER,SMPS[COIL]
V101 9965 000 19235
!
VARISTOR SVC681D-10A
CAPACITORS
C101 9965 000 18666
!
CAP 0.1UF 275V
C102 9965 000 18666
!
CAP 0.1UF 275V
C103 9965 000 18667 ELCAP 100UF 400V
C105 9965 000 18669 FILM CAP 0.01UF D 630V 10%
C106 9965 000 25551 CAP HIGH-VOL 68PF 1KV
C110 9965 000 18672
!
CERAMIC 1000PF 400V
C111 9965 000 18672
!
CERAMIC 1000PF 400V
C127 4822 124 40201 1000UF 20% 16V
C129 9965 000 25552 ELCAP 2200UF 16V 20%
C131 4822 124 40184 1000UF 20% 10V
C163 9965 000 25553 CAP HI-VOL 470P 1KVDC
RESISTORS
R100 9965 000 19226 1.5M OHM 1/2W 5.00% MF10
R101 9965 000 19227 2.7/2W CEMENT SMPS V
R104 9965 000 19228 56K OHM 2W 5.00% TR
COILS & FILTERS
L102 9965 000 25557
!
FILTER SHT LFSQ2215V4-04220
L102 9965 000 25556
!
FILTER KSE-145E KSE (ALTERNATIVE)
L125 9965 000 19213 CHOKE COIL 20UH
DIODES
BD101 9965 000 18662 S1WBA60(1A 600V)
D101 9965 000 18682 ERA22-10 KFLB,TP ,R T/P,FUJI
D102 9965 000 18683 EU01W(R-FORM) TP SANKEN
D106 9965 000 18565 RL104F TP RECTRON NON 400V 1A
D110 9965 000 25554 RU4YX BK (ALTERNATIVE)
D110 9965 000 18684 HER302 BK RECTRON DO201AD 100V
D111 9965 000 18685 1N5822 BK RECTRON DO201AD 40V
D113 9965 000 18565 RL104F TP RECTRON NON 400V 1A
D118 9965 000 18687 B10A45V1 BK KEC TO220 45V 10A
ZD102 9965 000 25559 UZ-22BSB 26MM
TRANSISTORS & INTEGRATED CIRCUITS
IC101 9965 000 25555 IC FSDL0365RN 8PIN,DIP
IC102 9965 000 18689
!
LTV-817B,PHOTO COUPLER(LITEON)
IC103 4822 209 12767 KIA431
Note: Only the parts mentioned in this list are normal service spare parts.
MAIN BOARD ASSEMBLY
MISCELLANEOUS
323 9965 000 25560 CASE ASSEMBLY
CS501 9965 000 25563 SWITCH MPU12970MLB0
ES501 9965 000 25564 HOLDER ASSY VCR DECK/MECHA END
ES502 9965 000 25564 HOLDER ASSY VCR DECK/MECHA END
JK5L1 9965 000 25584 FRONT A/V-IN DPAE-0385
JK902 9965 000 25585 RGB / AV CONN. RCA-910A-00-01
JK903 9965 000 25586 OPTICAL OUT PLT131/T5/12(12MBPS)
JK904 9965 000 25587 S-VIDEO OUT DIN405
LD501 9965 000 25592 HOLDER ASSY, VCR DECK/MECHA END
MS501 9965 000 25595 SWITCH MMS01080ZMBO 5VDC 1MA D37
MS501 9965 000 25594 SWSSS-51MD-3 5V 1MA (ALTERNATIVE)
RC501 9965 000 25601 IR RECEIVER TSOP2236AY1
RS501 9965 000 25602 KIT-3001A REEL SENSOR
RS502 9965 000 25602 KIT-3001A REEL SENSOR
SC901 9965 000 25603 DOUBLE - SCART DSAM-0341
SW502 9965 000 25604 TACT SWITCH THVV951BAA
SW503 9965 000 25604 TACT SWITCH THVV951BAA
SW504 9965 000 25604 TACT SWITCH THVV951BAA
SW505 9965 000 25604 TACT SWITCH THVV951BAA
SW506 9965 000 25604 TACT SWITCH THVV951BAA
SW507 9965 000 25604 TACT SWITCH THVV951BAA
SW508 9965 000 25604 TACT SWITCH THVV951BAA
SW509 9965 000 25604 TACT SWITCH THVV951BAA
SW510 9965 000 25604 TACT SWITCH THVV951BAA
SW511 9965 000 25604 TACT SWITCH THVV951BAA
SW511 9965 000 25605 TACT SW EVQ 213 09K (ALTERNATIVE)
SW511 9965 000 25606 TACT SWITCH SKHVBG3910-AA (ALT.)
SW512 9965 000 25604 TACT SWITCH THVV951BAA
SW512 9965 000 25605 TACT SW EVQ 213 09K (ALTERNATIVE)
SW512 9965 000 25606 TACT SWITCH SKHVBG3910-AA (ALT.)
SW513 9965 000 25604 TACT SWITCH THVV951BAA
SW513 9965 000 25605 TACT SW EVQ 213 09K (ALTERNATIVE)
SW513 9965 000 25606 TACT SWITCH SKHVBG3910-AA (ALT.)
SW514 9965 000 25604 TACT SWITCH THVV951BAA
SW514 9965 000 25606 TACT SWITCH SKHVBG3910-AA (ALT.)
SW514 9965 000 25605 TACT SW EVQ 213 09K (ALTERNATIVE)
TU701 9965 000 25607 TUNER UNIT TADM-M101D /00/05/14
TU701 9965 000 25672 TUNER UNIT TADM-S101D /02
TU701 9965 000 25608 TUNER UNIT TCMK0601PD20C PAL F
(ALTERNATIVE)
X301 9965 000 25609 X’AL 4.433619MHZ HC-49S
X501 9965 000 18658 X’TAL 10MHZ +/- 30 PPM
X501 9965 000 25610 X’TAL 10-0000MHZ 30P (ALTERNATIVE)
X502 9965 000 25611 X’TAL 32.768KHZ
X502 9965 000 18659 X’TAL 32.768KHZ (ALTERNATIVE)
X601 9965 000 18582 X’TA27MHZ 20PPM 1
X751 9965 000 18660 X’TAL 18432000HZ 30PPM 16
X751 9965 000 25612 X’TAL 18.432MHZ +/- 3 (ALTERNATIVE)
