18 19First steps First steps
Table of contents
Table of contents
3
Insert the memory card until it snaps into place.
4
To remove the card press the memory card slightly until the
snapping mechanism unlocks and the card is ejected.
Note
• To ensure that the device stores the recordings on the memory
card, you must switch from the internal memory to microSD
memory card (see also chapter 9.1.1 Set file location, page
38). The display shows a folder icon which indicates where
the recordings are currently being stored: u, v, w, x,
y–internal memory, à, á, â, ã, ä–memory card.
4.7 Pull out the stand (DVT6010–DVT8010)
Use the stand on the rear side of the device when you stand it on a
table, for example to record a meeting. This way you can get the most
of the microphone on the rear side of the device.
1
Pull out the stand on the back of the unit.
2
Place the unit on a flat surface, such as a table.
4.8 Using the remote control (DVT8010)
The battery is already inserted in the remote control. It is protected
by a plastic strip to ensure that no power is consumed during
transportation.
1
Pull out the plastic strip from the battery compartment on the
bottom of the remote control.
4.9 How to use the remote control (DVT8010)
Note
• Replace the battery when the remote control stops working
(see also chapter 10.2 Replacing the remote control battery
(DVT8010), page 52).
• Remove the battery from the remote control if it will be stored
unused for an extended period of time. The remote control can
be damaged by a leaking battery.
• Used batteries and rechargeable batteries should be disposed of
at an ocial collection point.
Point the remote control at the receiver on the side of the device. The
angle of the device should not exceed 80 degrees; the distance should
not exceed three meters. Make sure there are no objects located
between the remote control and the device.
If the device is operated using the remote control, large symbols are
displayed on the screen instead of the normal views.
