Philips EasyKey Alpha-VP-5HWS User Manual

4
Exploded views
1.
2.
3.
4.
5.
6.
7.
Screen x1
Lithium battery x1
M6 anchor screw x2
Rear escutcheon x1
Compressed spring x2
Square shaft x2
M5 anchor screw x2
8.
9.
10.
11.
12.
13.
Mounting plate x1
Mortise x1
M5 threaded pipe x2
M6 threaded pipe x2
Front escutcheon x1
Screw cap x1
1
1
22 33 44
55
66
77
88
99 1010
1111
1212
1313
1
