5
Loosen the screws by turning them
counterclockwise with an Allen
wrench and remove the mortise
plate.
Mount the mortise plate and
fasten it with screws.
Take out the latch bolt and rotate
it to 180°, then put it back.
Pre-setup instructions
1. Please choose the proper installation kit to suit your door thickness.
2. The default installation kit is applicable for a door thickness of 60-90mm. If your
door thickness does not within this range, please feel free to contact us.
Left-handed door Right-handed door
Left inward
Left outward
Mortise plate
Mortise plate
Allen wrench
Latch
bolt
Allen wrench
Right inward
Right outward
Attention
Step 1 | Determine door swing direction
This product allows you to have your door installed to go in four directions:
left outward, right outward, left inward and right inward.
Step 2 | Change the orientation of the latch bolt
1
3
2
To Next Page
