Electrical Alignments
EN 110 EM5.1E8.
Figure 8-6 Option bytes Group 1
OB Bit Option name Settings (in decimal values) for EM5.1E chassis Option
number
0
1
2
Featurebox 0= None
2= Prozonic
3= Eagle
4= Falconic
5= Falconic 1050i 1250i
3 2D Comb Filter 0= Off 8= On
4 Auto-Scavem 0= Off 16= On
5 n.a. * 0
6 Light Sensor 0= Off 64= On
7 Luma Trans. Proc. 0= Off 128= On (for non-Eagle sets)
8 n.a. * 0
9 n.a. * 0
10 n.a. * 0
11 n.a. * 0
12 WSS 0= Off 4096= On
13 3D Comb Filter 0= Off 8192= On
14 Pixel Plus 0= Off 16384= On
1
15 n.a. * 0
Sum OB1
(decimal)
0 n.a. * 0
1 Dolby ProLogic 0= Off 2= On
2 Virtual Rear Spkrs 0= Off 4= On
3 Cordless Rear Spkrs 0= Off 8= On
4 Dolby Digital 0= Off 16= On
5 Virtual Dolby 0= Off 32= On
6
7
Subwoofer 0= No subwoofer present
64= Subwoofer present
8
9
10
11
Chassis 0= EM6
256= EM5
512= EM3
3840= Others
12 EPG Type 0= Off (US) 8192= On (EU)
13 Flash RAM 0= Off (US) 8192= On (EU)
14
2
15
EPG Version 0= Off (US)
16384= Text guide only
32768= NexTView 2C3 (EU)
49152= NexTView 2
Sum OB2
(decimal)
0 n.a. * 0
1 n.a. * 0
2 AV4 (2fH) 0= Off 4= On (not selectable)
3 AV3 (2fH) 0= Off 8= On (not selectable)
4 Dual Screen 0= Off 16= On
5 n.a. * 0
6 TXT/EPG/DS 0= Off 64= On
7 n.a. * 0
8 Aspect Ratio 0= 4:3 256= 16:9
9 Tilt 0= Off 512= On
10 Monitor 0= Off 1024= Reserved for FTV
11 Integrated Radio 0= Off 2048= On
12 Stand Alone 0= Off 4096= Reserved for FTV
13 Integrated DVD 0= Off 8192= On (not appl. for FTV)
14 Home Cinema 0= Off 16384= On
3
15 Integrated RC (P50) 0= Off 32768= On
Sum OB3
(decimal)
0 PIP/Aux. Tuner 0= Off 1= On
1 n.a. * 0
2 China IF 0= Off 4= On
3 Tuner 0= Philips 8= Alps
4 Teletext 0= Off 16= On
5 n.a. * 0
6 n.a. * 0
7 n.a. * 0
8 Digital Module (MILO) 0= Off 256= On
9 Integrated Harddisk 0= Off 512= On
10 n.a. * 0
11 n.a. * 0
12 Anti Aging 0= Off 4096= Reserved for FTV
13 DVD-door lock 0= Off 8192= On
14 n.a. * 0
4
15 n.a. * 0
Sum OB4
(decimal)
Note:
Bits that are not used have a fixed value of "0", and are not mentioned in above overview.
CL 36532017_052.eps
