Philips EM5.1E - Page 111

Electrical Alignments
EN 111EM5.1E 8.
Figure 8-7 Option bytes Group 2
OB Bit Option name Settings (in decimal values) for F22Rx_AA chassis Option
Number
0 n.a. * 0
1
2
Auto Store Mode 0= None 2= PDC/VPS
4= TXT Page
6= PDC/VPS/TXT Page
3 Korean Stereo 0= Off 8= On
4 Picture Mute 0= Off 16= On
5 n.a. * 0
6 Virgin 0= Off 64= On
7 n.a. * 0
8 n.a. * 0
9 n.a. * 0
10 n.a. * 0
11 n.a. * 0
12 TXT Preference 0= TOP 4096= FLOF
13 n.a. * 0
14 n.a. * 0
5
15 n.a. * 0
Sum OB5
(decimal)
0 P50 DVD menu-line 0= Off 1= On
1 n.a. * 0
2 n.a. * 0
3 n.a. * 0
4
5
6
7
Region 0= EU 16= AP PAL-multi
32= AP NTSC
48= US
64= LATAM
80= Australia
8 n.a. * 0
9 n.a. * 0
10 n.a. * 0
11 n.a. * 0
12 n.a. * 0
13 n.a. * 0
14 n.a. * 0
6
15 n.a. * 0
Sum OB6
(decimal)
0 EXT4 1fH (EU) 0= Off (EM5) 1= On
1 EXT 2fH 1 (EU) 0= Off (EM5) 2= On
2 EXT 2fH 2 (EU) 0= Off 4= On
3 EXT VGA (EU) 0= Off 8= On
4 EXT DVI (EU) 0= Off 16= On
5 EXT3 (EU) 0= Off 32= On
6 n.a. * 0
7 n.a. * 0
8 n.a. * 0
9 AV 2fH 1 (non-EU) 0= Off 512= On
10 AV 2fH 2 (non-EU) 0= Off 1024= On
11 AV VGA (non-EU) 0= Off 2048= On
12 AV DVI (non-EU) 0= Off 4096= On
13 n.a. * 0
14 n.a. * 0
7
15 n.a. * 0
Sum OB7
(decimal)
0
1
2
3
Cabinet 0= FL6 1= FL7
2= FL8
3= FL9 DAS
4= FL9 Monitor
5= FL10
6= FL11
7= FL12
8= FL14 (n.a.)
9= PV02
10= FL13
11= Soft Design Line
12= Tech Design Line
4 n.a. * 0
5 n.a. * 0
6 AVL 0= Off 64= On
7 n.a. * 0
8
9
10
11
Picture tube size 0= 28 inch 256= 32 inch
512= 36 inch
768= 29 inch
1024= 34 inch
1280= 38 inch
1536= 32 inch MEC
1792= 28 inch Mk2
2048= 36 inch FP
3840= Other
12 Anti MoirÈ 0= Off 4096= On
13 n.a. * 0
14 n.a. * 0
8
15 n.a. * 0
Sum OB8
(decimal)
Note:
Bits that are not used have a fixed value of "0", and are not mentioned in above overview.
CL 36532017_053.eps
240403
