2.2 What you also need (not supplied)?
2.3 Overview
Front panel
5
2 3
8
9
1
6
4
7
10
Rear panel
9
1
2 3 4
5 6 7 8
10
Remote control
TEXT RADIO EXIT
GUIDE OPTIONS
BACKINFO
DIGITAL RECORDER
MENU
HDD
LIB
AD
1
2
6
4
5
3
Front Panel
1  Standbyindicator
2  Standbybutton
3  Programme+/-buttons
4  Resolutionbutton
5  V-Outbutton
6 Display
7  HDindicator
8  Recordindicator
9  USB2.0connector
10 Toplighting
Rear Panel
1  AntennaIN
*
2  AntennaoutputtoTV/VCR(antennasignal)
*
3  OpticalS/PDIFaudioout(digital)
*
4  USB2.0connector
*
5  RJ45Ethernetconnector
*
6  AUXSCARTconnector
*
7  DIGITALaudioout(digital)
*
8  L/Raudioout(analogue)
*
9  HDMI™connector
*
10 12Vpowerconnector
*
*
 Safeextralowvoltage
Remote control
1  Standby
2  Text,Pictureformat,Radio,Exit,TVguide,
  Menu,Options
3  Up/Down,Left/Right,OK,Info,Back
4  Recorderfunctions
5  Volumecontrol,Mute,Programme+/-
6  Alphanumerickeypad,Audiodescription,
  Subtitles
TV
SCARTcable
(requiredonlyifyouhavea
standard-denitionTV)
