Philips LC4.9E - Page 138

Alignments
EN 138 LC4.9E AB8.
Table 8-3 Option codes in detail, at bit level
Option byte & bit table for restoring the TV set to its original Factory Default settings via the NVM Editor in the SAM menu
Model number
42PF7520D/10 42PF5520D/10
OP1 Description of feature/option to be switched ON or OFF
bit 7 (msb) OP_PHILIPS_TUNER 11
bit 6 OP_FM_RADIO 00
bit 5 OP_LNA 00
bit 4 OP_ATS // for EU 11
bit 3 OP_ACI 11
bit 2 OP_UK_PNP 00
bit 1 OP_VIRGIN_MODE 00
bit 0 (lsb) OP_CHINA 00
Total DEC Value 152 152
Total HEX Value 98 98
OP2
bit 7 (msb) OP_SC 00
bit 6 OP_IBEX 11
bit 5 OP_CHANNEL_NAMING 11
bit 4 OP_LTI (Lum Transcient Improvmt) 00
bit 3 OP_TILT 00
bit 2 OP_FINE_TUNING 11
bit 1 OP_PIP_PHILIPS_TUNER 00
bit 0 (lsb) OP_HUE 11
Total DEC Value 101 101
Total HEX Value 65 65
OP3
bit 7 (msb) OP_EW_FUNCTION 00
bit 6 OP_PIXEL_PLUS 10
bit 5 OP_PIP_SPLITTER // temp 00
bit 4 OP_SPLITTER // temp 00
bit 3 OP_VIRTUAL_DOLBY 11
bit 2 OP_WIDE_SCREEN 11
bit 1 OP_WSSB 11
bit 0 (lsb) OP_OP_ME5 // OP_ME5 - 5/6 local buttons implementation 11
Total DEC Value 79 15
Total HEX Value 4F 0F
OP4
bit 7 (msb) OP_LIP_SYNC 11
bit 6 OP_HD 11
bit 5 OP_ULTRA_BASS 11
bit 4 OP_DELTA_VOLUME 11
bit 3 OP_TAIWAN_KOREA 00
bit 2 OP_VOLUME_LIMITER 00
bit 1 OP_STEREO_DBX 00
bit 0 (lsb) OP_STEREO_NICAM_2CS 11
Total DEC Value 241 241
Total HEX Value F1 F1
OP5
bit 7 (msb) OP_AV1 11
bit 6 OP_AV2 11
bit 5 OP_AV3 11
bit 4 OP_CVI 11
bit 3 OP_SVHS2 11
bit 2 OP_SVHS3 11
bit 1 OP_HOTEL_MODE 00
bit 0 (lsb) OP_SIMPLY_FACTORY=OP_BTSC_AVSTEREO 00
Total DEC Value 252 252
Total HEX Value FC FC
OP6
bit 7 (msb) OP_PERSONAL_ZAPPING 00
bit 6 OP_SMART_SURF 00
bit 5 OP_FMTRAP 00
bit 4 OP_COMBFILTER 11
bit 3 OP_ACTIVE_CONTROL 11
bit 2 OP_VIDEO_TEXT 00
bit 1 OP_LIGHT_SENSOR 11
bit 0 (lsb) OP_TWIN_TEXT 11
Total DEC Value 27 27
Total HEX Value 1B 1B
OP7
bit 7 (msb) OP_TIME_WIN1 00
bit 6 OP_DVB_USB = OP_MALAY 00
bit 5 OP_AMBILIGHT 00
bit 4 OP_COLUMBUS 11
bit 3 OP_DUMMY6 00
bit 2 OP_DUMMY7 00
bit 1 OP_WEST_EU 11
bit 0 (lsb) OP_MULTI_STANDARD_EUR 11
Total DEC Value 19 19
Total HEX Value 03 03
