Philips LX8500W Service Manual

D
A
B
C
D
1300 A3
1301 C2
1302 B1
1303 B2
1304 B2
1305 B3
1306 B1
123
123
A
B
C
1307 A1
1308 A1
1309 A2
1310 C1
1311 D1
2300 B1
2301 A1
3300 A2
3301 A1
3302 B2
3303 B2
3304 B2
3305 B1
GND_D
1309
220R
3301
1
1311
SIN-01T-1.81
GND_D
GND_D
A
1
B
3
C
2 4 5
SIN-01T-1.8
1310
GND_D
1301
SRGP
2301
100p
GND_D
3300
GND_D
150R
1308 1307
1305 1306
1
2
3
4
5
GND_D
1304
GND_D
GND_D
1300
FE-ST-VK-N
3302
150R
GND_D
1302
390R
GND_D
220R
3305 3303
1303
GND_D GND_D
GND_D
100p 2300
key1
key0
volB
volA
3304
270R
3139 113 35425_3139 113 3553 pt5_dd wk0428
1100 4822 265 31205 FLEX CONNECTOR 5P
1102 2422 025 14518 FLEX CONNECTOR 9P
1103 2422 025 16586 FLEX CONNECTOR 9P
1103 2422 025 05587 FLEX CONNECTOR 9P
1107 2422 025 17411 FLEX CONNECTOR 30P
COILS & FILTERS
5100 4822 157 10586 FXD IND 2,2uH 10%
5102 2422 540 98518 RES CER 8MHz CSTS*MG03
DIODES
6100 4822 130 30621 1N4148
6101 4822 130 30621 1N4148
6102 4822 130 30621 1N4148
6104 4822 130 11148 BZX384-C4V7
6110 4822 130 11397 BAS316
6111 4822 130 11397 BAS316
6112 4822 130 11397 BAS316
6113 4822 130 11397 BAS316
6114 4822 130 11397 BAS316
6115 4822 130 11397 BAS316
6116 4822 130 11397 BAS316
6117 4822 130 11397 BAS316
6118 4822 130 11397 BAS316
6119 4822 130 11397 BAS316
6120 4822 130 11397 BAS316
6121 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7101 5322 130 60159 BC847B
7102 5322 130 60159 BC847B
7103 3139 240 50941 TMP87CM74AF - ‘LX8300S50941’
7104 5322 130 60159 BC847B
Note : Only the parts mentioned in this list are normal service
spare parts.
1201 2422 025 17414 FLEX CONNECTOR 30P
1202 3139 111 04051 FTD FV818GN
DIODES
6200 9322 179 76676 LED VS LTL-816EELC
6201 9322 190 55676 LED VS LTL-816TDK3
6202 3198 020 55680 BZX384-C5V6
TRANSISTORS & INTEGRATED CIRCUITS
7200 9322 185 95667 IR RECEIVER TSOP4836YA1
7201 4822 130 60373 BC857B
7202 5322 130 60159 BC847B
7203 4822 130 42804 BC817-25
7204 4822 130 60373 BC857B
7205 4822 130 42804 BC817-25
Note : Only the parts mentioned in this list are normal service
spare parts.
1300 4822 267 10958 FLEX CONNECTOR 5P
1301 2422 129 16936 ROT ENCODER 32P
1302 4822 276 13775 TACT SWITCH
1303 4822 276 13775 TACT SWITCH
1304 4822 276 13775 TACT SWITCH
1305 4822 276 13775 TACT SWITCH
1306 4822 276 13775 TACT SWITCH
1307 4822 276 13775 TACT SWITCH
1308 4822 276 13775 TACT SWITCH
1309 4822 276 13775 TACT SWITCH
Note : Only the parts mentioned in this list are normal service
spare parts.
ELECTRICAL PARTS LIST - FRONT BOARD
MISCELLANEOUS
ELECTRICAL PARTS LIST - IR/FTD/LED BOARD
MISCELLANEOUS
ELECTRICAL PARTS LIST - FRONT KEY BOARD
MISCELLANEOUS
6-7
6-7
FRONT KEY BOARD - CIRCUIT DIAGRAM

Philips LX8500W Specifications

Sound Specifications

D/A converter	24 bit, 96 kHz
frequency response	30-48000 Hz
signal to noise ratio	>95 dB
output power (RMS)	3 x 100W, 2 x 75W + 150W
total sound power (RMS)	600 W
satellite speaker frequency range	120-50000 Hz
satellite speaker impedance	6 ohm
center frequency range	120-30000 Hz
center speaker impedance	6 ohm
subwoofer frequency range	30-120 Hz
subwoofer impedance	4 ohm

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 1W

Weight and Dimensions

center speaker dimensions	435 x 76 x 70 mm
center speaker weight	1.4 kg
packaging dimensions	1000 x 516 x 495 mm
set dimensions	360 x 40 x 305 mm
set weight	2.5 kg
stand dimensions	95 x 540 x 95 mm
subwoofer dimensions	300 x 400 x 300 mm
subwoofer weight	12 kg
surround speaker dimensions	100 x 550 x 107 mm
surround speaker weight	10.3 kg
weight including packaging	43 kg
