DVD Loader
AV Board
Tuner Module
SD6.3 Board
Front Board
Front Key Board
Front IR/FTD/LED Board
1-2
LOCATION OF PC BOARDS
/01 /04 /05
Progressive Scan x x x
Voltage Selector
Digital In x x x
TV-In
Aux-In x x x
Line-Out x x x
Video Output x x x
S-Video Output x x x
SCART x x x
Y/Pb/Pr (YUV) Component Video Output x x x
VERSION VARIATIONS:
Type /Versions: LX8300SA
Features &
Board in used:
