Philips LX8500W Service Manual

7-10
7-10
ELECTRICAL PARTS LIST - AV BOARD
MISCELLANEOUS
ELECTRICAL PARTS LIST - AV BOARD
1100 4822 267 11039 Flex Connector 11P
1103 2422 026 05462 Socket Cinch 4P (Aux-in/Line-out)
1200 2422 025 17433 Flex Connector 30P
1200 2422 025 17509 Flex Connector 30P
1400 2422 025 18315 Socket SCART 21P
1400 2422 025 12352 Socket SCART 21P
1401 2422 025 17433 Flex Connector 30P
1401 2422 025 17509 Flex Connector 30P
1402 3139 241 21102 EMC SPRING
1403 3139 241 21102 EMC SPRING
1407 2422 026 05531 Socket Cinch 1P (Pr)
1408 2422 026 05529 Socket Cinch 2P (Y/Pb)
1409 2422 033 00468 Socket 2P (Video/S-Video)
1411 2422 026 05427 Socket Cinch 1P (Digital In)
1507 2422 025 14518 Flex Connector 9P
1509 2422 025 05561 Socket MDR 36P
1509 2422 025 18466 Socket MDR 36P
1511 2422 025 16525 Flex Connector 16P
COILS & FILTERS
5216 2422 549 43062 FXD IND 0603 100MHZ 600R
5217 2422 549 43062 FXD IND 0603 100MHZ 600R
5220 2422 549 43062 FXD IND 0603 100MHZ 600R
5221 2422 549 43062 FXD IND 0603 100MHZ 600R
5222 2422 549 43062 FXD IND 0603 100MHZ 600R
5223 2422 549 43062 FXD IND 0603 100MHZ 600R
5231 4822 242 11033 RES XTL 4,332MHZ
5400 3198 018 41880 FXD IND SM 1210 1U8 5%
5401 3198 018 41880 FXD IND SM 1210 1U8 5%
5402 3198 018 41880 FXD IND SM 1210 1U8 5%
5403 3198 018 41880 FXD IND SM 1210 1U8 5%
5404 3198 018 41880 FXD IND SM 1210 1U8 5%
5405 3198 018 41880 FXD IND SM 1210 1U8 5%
5406 3198 018 90050 FXD IND 0603 100MHz 1K
5407 3198 018 90050 FXD IND 0603 100MHz 1K
5408 3198 018 90050 FXD IND 0603 100MHz 1K
5409 3198 018 90050 FXD IND 0603 100MHz 1K
5505 4822 157 11717 IND FXD 1206 EMI 100MHz 50R
5507 4822 157 11717 IND FXD 1206 EMI 100MHz 50R
DIODES
6101 4822 130 11551 BZX384-C10
6201 3198 020 55680 BZX384-C5V6
6202 4822 130 11397 BAS316
6203 4822 130 11397 BAS316
6204 4822 130 11397 BAS316
6205 4822 130 11397 BAS316
6206 4822 130 11397 BAS316
6208 4822 130 11397 BAS316
6209 4822 130 11397 BAS316
6210 3198 020 55680 BZX384-C5V6
6401 4822 130 11397 BAS316
6406 9340 548 67115 BZX384-C22
6407 4822 130 11522 BZX384-C15
6408 4822 130 11522 BZX384-C15
6409 4822 130 11522 BZX384-C15
6417 4822 130 11522 BZX384-C15
6505 3198 010 10720 DIO REC SS24
6506 9322 128 69685 DIO REC SM S1D
TRANSISTORS & INTEGRATED CIRCUITS
7100 5322 130 44647 BC368
7101 5322 130 60159 BC847B
7102 5322 130 60159 BC847B
7103 4822 130 60373 BC857B
7104 4822 209 30095 LM833D
7105 5322 209 11102 HEF4052BT
7200 9322 203 36668 IC SM CS42418-CQ
7201 9352 686 05118 IC SM SAA6581T
7202 4822 130 40959 BC547B
7210 4822 130 60373 BC857B
7213 4822 130 40959 BC547B
7300 4822 209 30095 LM833D
7301 4822 209 30095 LM833D
7302 4822 209 30095 LM833D
7303 4822 130 60373 BC857B
7305 4822 130 60373 BC857B
7306 5322 130 60159 BC847B
7307 5322 130 60159 BC847B
7308 5322 130 60159 BC847B
7309 5322 130 60159 BC847B
7310 5322 130 60159 BC847B
7311 5322 130 60159 BC847B
7312 5322 130 60159 BC847B
7313 5322 130 60159 BC847B
7322 5322 130 60159 BC847B
7323 5322 130 60159 BC847B
7324 5322 130 60159 BC847B
7325 5322 130 60159 BC847B
7400 4822 130 60373 BC857B
7401 4822 130 60373 BC857B
7402 4822 130 60373 BC857B
7403 4822 130 60373 BC857B
7404 4822 130 60373 BC857B
7405 4822 130 60373 BC857B
7411 5322 130 60159 BC847B
7416 4822 130 60373 BC857B
7417 5322 130 60159 BC847B
7418 5322 130 60159 BC847B
7420 4822 130 60373 BC857B
7421 5322 130 60159 BC847B
7422 4822 130 60373 BC857B
7423 5322 130 60159 BC847B
7425 4822 130 60373 BC857B
7426 4822 130 60373 BC857B
7501 4822 209 17398 LD1117DT33
7501 4822 209 17398 LD1117DT33
7502 5322 130 62804 BCP53
7503 5322 130 60159 BC847B
7504 9322 146 75685 IC SM TS431IL
7505 9322 199 24668 IC SM L7808CD2T
7506 4822 130 60373 BC857B
7508 4822 209 17398 LD1117DT33
7508 4822 209 17398 LD1117DT33
7509 5322 130 60159 BC847B
7512 4822 209 30095 LM833D
7513 5322 130 60159 BC847B
7600 4822 209 30095 LM833D
7601 5322 130 60159 BC847B
7602 5322 130 60159 BC847B
7603 5322 130 60159 BC847B
7604 5322 130 60159 BC847B
7607 5322 130 60159 BC847B
7608 5322 130 60159 BC847B
7609 5322 130 60159 BC847B
7610 5322 130 60159 BC847B
7612 4822 130 60373 BC857B
7614 5322 130 60159 BC847B
7615 5322 130 60159 BC847B
7616 5322 130 60159 BC847B
7617 5322 130 60159 BC847B
7618 4822 209 30095 LM833D
7619 4822 209 30095 LM833D
Note : Only the parts mentioned in this list are normal service
spare parts.

Philips LX8500W Specifications

Sound Specifications

D/A converter	24 bit, 96 kHz
frequency response	30-48000 Hz
signal to noise ratio	>95 dB
output power (RMS)	3 x 100W, 2 x 75W + 150W
total sound power (RMS)	600 W
satellite speaker frequency range	120-50000 Hz
satellite speaker impedance	6 ohm
center frequency range	120-30000 Hz
center speaker impedance	6 ohm
subwoofer frequency range	30-120 Hz
subwoofer impedance	4 ohm

Power

power supply	110-240V, 50/60 Hz
standby power consumption	< 1W

Weight and Dimensions

center speaker dimensions	435 x 76 x 70 mm
center speaker weight	1.4 kg
packaging dimensions	1000 x 516 x 495 mm
set dimensions	360 x 40 x 305 mm
set weight	2.5 kg
stand dimensions	95 x 540 x 95 mm
subwoofer dimensions	300 x 400 x 300 mm
subwoofer weight	12 kg
surround speaker dimensions	100 x 550 x 107 mm
surround speaker weight	10.3 kg
weight including packaging	43 kg
