Introducing the Instrument Components
Introduction to the Instrument
3
The signals are converted into digital data, and processed before being communicated to the
Monitor. The server device is referred to as the Measurement Server or simply the Server in
this manual. All versions of the M3000A and M3001A Measurement Servers are covered by
this manual.
When using the M3015A and M3016A, all the signals are converted into digital data, and
processed before being communicated to the Monitor. Server extension devices are referred
to as the Measurement Server Extensions or simply Extensions in this manual.
The M3046A Compact Portable Patient Monitor receives the processed data from the
Measurement Server and the Measurement Server Extension, examines it for alarm
conditions, and displays it. The Monitor also provides operating controls for the user, and
interfaces to other devices. This monitoring device is referred to as the Monitor in this
manual.
The M3080A #C32 12V adapter allows use of a vehicle power supply for the instrument and
the M8043A Battery Charger and Conditioner allows the recharging and conditioning of
batteries of the instrument.
M3001A #C06
!!!!!!!
"" "
!
M3001A #C12
!!!!!
"""" "
!
M3001A #C18
!!!!!!!
"" "
!
M3012A
b
"""""!!"
""
!
M3015A
c
""""""""
!! !
M3015A #C06
c
"""""
!!
"
!! !
M3016A #A01
c
"""""
!!!
"
!!
M3016A #A02
c
"""""
!!
""
!!
Key: ! = supported " = not supported
a. Using a standard 5-electrode lead set. You can connect a 10-electrode lead set (for example, if a patient is
transferred from an IntelliVue monitor), but only the standard five electrodes (RA, LA, RL, LL, and V) are
used for monitoring. The rest are automatically ignored.
b. Only Pressure/Temperature supported in M4 monitors.
c. Support for the CO
2
measurement depends on the monitor option and software revision. Compatible with M3/
M4 with software revision E and D (later than D.11). Compatible with M4 only with software revision B to
D.11. No support for CO
2
for earlier monitors with software revision A.
Measurement
Server/Server
Extension
withOption
Measurements Compatible with
which M3046A
Release?
3-Channel ECG
EASI derived
a
12-Lead ECG
Respiration
Non-Invasive
Blood Pressure
Oxygen Saturation
SpO
2
Invasive
Blood Pressure
Temperature
Mainstream CO
2
Sidestream CO
2
D and
lower
E
