Philips MCD288/12 - Page 37

12-2
ELECTRICAL PARTS LIST
- ECO POWER BOARD(ONLY FOR /12/37)
Q2201 9940 000 02518 TRANSISTOR 8050C
REL1201 9940 000 03509 RELAY 10A 240VAC/30VDC
9940 000 04649 ECO POWER TRASFO.
Note: Only these parts mentioned in the list are
normal service parts.
!
ELECTRICAL PARTS LIST
- SCART BOARD (ONLY FOR /12)
JCK801 9940 000 04983 RCA SOCKET AV-8.4-0.8B
JCK802 9940 000 03511 SCART 21P SOCKET
JCK803 9940 000 04944 AV OUT SOCKET 4P
Q801 9940 000 02545 TRANSISTOR 9014C
Q802 9940 000 02519 TRANSISTOR 8550C
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTS LIST
- WOOFER OUTPUT BOARD
C506 9940 000 04971 CAP. 334J 100V
C524 9940 000 04972 MYLAR CAP. 5600P 100V
C560 9940 000 04973 ELEC. CAP. 4700µF 35V
C561 9940 000 04973 ELEC. CAP. 4700µF 35V
DB1 9940 000 03502 THYRISTOR RS808
F501 9940 000 03433 FUSE F6.3A L250V
F502 9940 000 03433 FUSE F6.3A L250V
IC1301 9940 000 03767 IC TDA7265
IC501 9940 000 04669 IC TL072
IC504 9940 000 04976 IC TDA7264
Q502 9940 000 04974 TRANSISTOR 8550-C
Q508 9940 000 02545 TRANSISTOR 9014C
Q509 9940 000 02545 TRANSISTOR 9014C
Q510 9940 000 02545 TRANSISTOR 9014C
Note: Only these parts mentioned in the list are
normal service parts.
!
!
ELECTRICAL PARTS LIST
- VIDEO OUTPUT BOARD(FOR /55/93/98)
JACK701 9940 000 04979 RCA SOCKET 2P B/Y
JACK702 9940 000 02553 3PINS RCA SOCKET(R/B/G)
JACK703 9940 000 04982 S-VIDEO OUTPUT SOCKET
Note: Only these parts mentioned in the list are
normal service parts.
