Philips MCD288/12 - Electrical Parts List

12-1
ELECTRICAL PARTS LIST
- DISPLAY BOARD
IC301 9940 000 04953 IC LM340T5 7805
IC302 9940 000 04957 CPU 3S9228
IC303 9940 000 04953 IC LM340T5 7805
IC304 9940 000 04951 IC 24C01A-SC27
IC305 9940 000 02539 IC PT6311
IC306 9940 000 02524 IC PT2309-S(L)
IC307 9940 000 03512 CHIP IC AC6811
IC308 9940 000 04956 IC TDA2579 /12
IC309 9940 000 04954 IC SA6208
LED301 9940 000 03437 LED 3B4SCB01
LED302 9940 000 03437 LED 3B4SCB01
LED303 9940 000 03437 LED 3B4SCB01
LED304 9940 000 03437 LED 3B4SCB01
LED305 9940 000 03437 LED 3B4SCB01
LED306 9940 000 03437 LED 3B4SCB01
LED307 9940 000 02537 LED (BLUE)
Q301 9940 000 02518 TRANSISTOR 8050C
Q302 9940 000 02519 TRANSISTOR 8550C
Q303 9940 000 02519 TRANSISTOR 8550C
Q304 9940 000 02518 TRANSISTOR 8050C
Q305 9940 000 02518 TRANSISTOR 8050C
Q306 9940 000 04949 TRANSISTOR 9014-C
Q307 9940 000 02518 TRANSISTOR 8050C
S301 9940 000 02542 IR SENSOR
SW305 9940 000 02543 LIGHT TOUCH SWITCH
SW306 9940 000 02543 LIGHT TOUCH SWITCH
SW307 9940 000 02543 LIGHT TOUCH SWITCH
SW308 9940 000 02543 LIGHT TOUCH SWITCH
SW309 9940 000 04964 LIGHT TOUCH SWITCH
SW310 9940 000 04964 LIGHT TOUCH SWITCH
SW311 9940 000 02543 LIGHT TOUCH SWITCH
SW312 9940 000 02543 LIGHT TOUCH SWITCH
X302 9940 000 03152 FILTER FREQ. 4.19MH
X303 9940 000 04962 CRYSTAL 4.332MHZ /12
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTS LIST
- POWER BOARD
C290 9940 000 04932 ELE. CAP. 3300µF 35V
CN201 9940 000 04943 S-SOCKET DS-106
CN204 9940 000 04944 AV OUT SOCKET 4P
CN209 9940 000 04939 LEADING-OUT TER. 15P
CN214 9940 000 04941 FM OUTPUT SOCKET
F201 9940 000 02529 FUSE F2A L250V
F501 9940 000 03433 FUSE F6.3A L250V
F502 9940 000 03433 FUSE F6.3A L250V
IC203 9940 000 04936 IC PT2313
IC204 9940 000 04935 IC LM2576-ADJP
IC502 9940 000 04937 IC 7812
JCK201 9940 000 04942 2PIN RCA SOCKET
L206 9940 000 04931 FIXED INDUCTOR 220µH
Q203 9940 000 02545 TRANSISTOR 9014C
Q204 9940 000 02519 TRANSISTOR 8550C
Q206 9940 000 02545 TRANSISTOR 9014C
Q207 9940 000 02545 TRANSISTOR 9014C
Q208 9940 000 02517 TRANSISTOR 2SB772
Q209 9940 000 02545 TRANSISTOR 9014C
R259 9940 000 03412 FUSE F1.5A/125V
Note: Only these parts mentioned in the list are
normal service parts.
!
!
