3-3 3-3
SERVICE POSITIONS & REPAIR HINTS
Service pos C
Service pos D
Service pos A
Service pos B
Note: In some service positions the components or copper
patterns of one board may risk touching its neigh-
bouring pc boards or metallic parts. To prevent such
short-circuit use a piece of hard paper or other
insulating material between them.
Paper
Paper
SERVICE POSITIONS & REPAIR HINTS
