ELECTRICAL PARTS LIST - AV (SCART) OUTPUT BOARD
MISCELLANEOUS
OP1 4822 130 10845 GP1F32T
P4 9965 000 10073 RCA SOCKET 1P BLACK
PS1 9965 000 10623 SCART CONNECTOR RT 21 PINS
S1 9965 000 10624 SW SLIDE 2P2T SKT-22F18
CAPACITORS
CA1* 9965 000 09652 CAP CER 0.1UF 50V +80/-20% Y5V
CA16 4822 126 14585 100NF 10% X7R 0805 50V
CA17 5322 122 34098 10NF10%X7R 63V
CA74 4822 126 13221 100PF 2% NP0 63V
CN1 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CN2 4822 122 33127 2,2NF10%X7R 63V
CN3 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CN4 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CN5 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CN6 4822 126 14585 100NF 10% X7R 0805 50V
CN7 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CN8 4822 122 33127 2,2NF10%X7R 63V
CN9 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CN10 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CN11 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CN12 4822 126 14585 100NF 10% X7R 0805 50V
CN13 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CN14 4822 122 33127 2,2NF10%X7R 63V
CN15 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CN16 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CN17 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CN18 4822 126 14585 100NF 10% X7R 0805 50V
CN19 4822 126 13221 100PF 2% NP0 63V
CN20 4822 126 13221 100PF 2% NP0 63V
CN21 9965 000 10625 CER SMD 47PF 50V 10% X7R 0805
CN22 9965 000 10625 CER SMD 47PF 50V 10% X7R 0805
CV7 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CV8 4822 122 32627 2.7NF10%X7R 50V
CV9 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CV10 9965 000 10115 CER SMD 390PF 50V 10% X7R 0805
CV12 4822 126 14585 100NF 10% X7R 0805 50V
CV13 9965 000 09655 CAP ELEC GR 220UF 16V 20%
RESISTORS
RA1 4822 051 20008 0R00 JUMP. (0805)
RA17 4822 051 20472 4K70 5% 0,1W
RA22 4822 117 11373 100R 1% RC12H 0805
RA23 4822 117 11448 180R 1% 0,1W
RA61 4822 051 20109 10R00 5% 0,1W
RN1 4822 117 11449 2K2 5% 0,1W 0805
RN2 4822 117 11927 75R 1% 0,1W
RN3 4822 117 11454 820R 1% 0,1W
RN4 4822 051 20129 12R00 5% 0,1W
RN5 4822 117 12322 8R2 2% 0,1W
RN6 4822 117 13528 200R 1% 0,125W 0805
RN7 4822 117 11449 2K2 5% 0,1W 0805
RN8 4822 117 11927 75R 1% 0,1W
RN9 4822 117 11454 820R 1% 0,1W
RN10 4822 051 20129 12R00 5% 0,1W
RN11 4822 117 12322 8R2 2% 0,1W
RN12 4822 117 13528 200R 1% 0,125W 0805
RN13 4822 117 11449 2K2 5% 0,1W 0805
RN14 4822 117 11927 75R 1% 0,1W
RN15 4822 117 11454 820R 1% 0,1W
RN16 4822 051 20129 12R00 5% 0,1W
RN17 4822 117 12322 8R2 2% 0,1W
RN18 4822 117 13528 200R 1% 0,125W 0805
RN19 4822 117 13528 200R 1% 0,125W 0805
RN20 4822 117 13528 200R 1% 0,125W 0805
RN22 4822 051 20102 1K00 5% 0,1W
RN23 4822 051 20102 1K00 5% 0,1W
RN24 4822 117 11449 2K2 5% 0,1W 0805
RN25 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
RN26 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
RN27 4822 117 12024 27K 1% 0.1W
RN28 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
RN29 4822 051 20472 4K70 5% 0,1W
RN30 9965 000 10156 RES SMD 12K OHM 5% 1/10W 0805
RN31 4822 051 20303 30K00 5% 0,1W
RN32 4822 051 20102 1K00 5% 0,1W
RN32 4822 117 13528 200R 1% 0,125W 0805
RN33 4822 051 20102 1K00 5% 0,1W
RN33 4822 117 13528 200R 1% 0,125W 0805
RV5 4822 117 11503 220R 1% 0.1W
RV6 4822 117 11454 820R 1% 0,1W
RV7 4822 117 11449 2K2 5% 0,1W 0805
RV8 4822 117 11927 75R 1% 0,1W
RV9 4822 117 12322 8R2 2% 0,1W
RV10 4822 051 20129 12R00 5% 0,1W
COILS & FILTERS
LN1 9965 000 10111 CHOKE 22UH 10% AXIAL EC24-220K
LN2 9965 000 10112 IND 2.7UH 10% AXIAL EC24-2R7K
LN3 9965 000 10111 CHOKE 22UH 10% AXIAL EC24-220K
LN4 9965 000 10112 IND 2.7UH 10% AXIAL EC24-2R7K
LN5 9965 000 10111 CHOKE 22UH 10% AXIAL EC24-220K
LN6 9965 000 10112 IND 2.7UH 10% AXIAL EC24-2R7K
LN7 9965 000 10622 IND CHOKE 6.8UH 10% EC24-6R8K
LN8 9965 000 10622 IND CHOKE 6.8UH 10% EC24-6R8K
LV3 9965 000 10111 CHOKE 22UH 10% AXIAL EC24-220K
LV4 9965 000 10112 IND 2.7UH 10% AXIAL EC24-2R7K
DIODES
DN1 4822 130 83338 LL4148
DN2 4822 130 83338 LL4148
DN3 4822 130 83338 LL4148
DN4 4822 130 83338 LL4148
DN5 4822 130 83338 LL4148
DN6 4822 130 83338 LL4148
TRANSISTORS & INTEGRATED CIRCUITS
QA3 4822 130 61074 2SA812M5
QA4 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
QN1 9965 000 10621 TR SMD 2SA1464 HFE300 400MHZ
QN2 9965 000 10621 TR SMD 2SA1464 HFE300 400MHZ
QN3 9965 000 10621 TR SMD 2SA1464 HFE300 400MHZ
QN4 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
QN5 4822 130 61074 2SA812M5
QN6 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
QN7 4822 130 61074 2SA812M5
QV1 9965 000 10621 TR SMD 2SA1464 HFE300 400MHZ
* SOLDERED OUTSIDE THE PC BOARD.
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
