ELECTRICAL PARTS LIST -- PSU BOARD
MISCELLANEOUS
AC 9965 000 09695
!
SOCKET 2-PIN 10MM A2361WV2-2P
F1 4822 070 36302
!
FUSE T6,3A 250V
F2 4822 070 32002
!
FUSE T2A 250V
F3 4822 070 32002
!
FUSE T2A 250V
F4 4822 070 32002
!
FUSE T2A 250V
F5 4822 070 31002
!
FUSE T1A 250V
J6 9965 000 09694 SOCKET 2-PIN 3.96MM A3960WV-
2P
JC6 9965 000 09697 SOCKET 3-PIN 5.08MM PITCH
JC7 9965 000 09696
!
SOCKET XFORMER A3961WV2-2 PIN
RLY1 9965 000 10634 RELAY 12VDC/10A SDT-SS-112DM
T1 9965 000 10633
!
M XFORMER 230V TT1-0123020-11
T2 9965 000 09688
!
STAND XFORMER EI-41 120V/230V
CAPACITORS
C1 9965 000 10629 CAP ELEC 220UF 50V 20% 105°C
C2 9965 000 10627 CAP ELEC 1UF 50V 20% 105°C
C3 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C4 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C5 9965 000 09671 CAP ELEC 4700UF 35V 20%
C6 9965 000 09671 CAP ELEC 4700UF 35V 20%
C7 9965 000 09671 CAP ELEC 4700UF 35V 20%
C8 9965 000 09671 CAP ELEC 4700UF 35V 20%
C9 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C10 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C11 9965 000 09666 CAP CER 0.1UF 100V 20% Y5V
C12 9965 000 09666 CAP CER 0.1UF 100V 20% Y5V
C13 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C14 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C15 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C16 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C17 9965 000 09671 CAP ELEC 4700UF 35V 20%
C18 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C19 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C20 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C21 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C22 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C23 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C24 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C25 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C26 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C27 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C28 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C29 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C30 9965 000 09652 CAP CER 0.1UF 50V +80/-20% Y5V
C33 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C34 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C35 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C36 9965 000 09667 CAP CER 0.022UF 50V +80/-20%
C37 9965 000 10626 CAP CER KX 2200PF 250VAC 20%
C38 9965 000 09670 CAP ELEC GR 47UF 35V 20%
C39 9965 000 09672
!
CAP MPF 0.47UF 250VAC 20%
C40 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
C41 9965 000 10628 CAP ELEC 220UF 16V 20% 105°C
RESISTORS
R1 9965 000 09684 RES CF 820 OHM 5% 1/6W AXIAL
R2 9965 000 09680 RES CF 4.7K OHM 5% 1/6W AXIAL
R3 9965 000 09680 RES CF 4.7K OHM 5% 1/6W AXIAL
R4 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R5 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R6 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R7 9965 000 09683 RES CF 7.5K OHM 5% 1/6W AXIAL
R8 9965 000 09677 RES CF 330 OHM 5% 1/6W AXIAL
R9 9965 000 09681 RES CF 560 OHM 5% 1/6W AXIAL
R10 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R11 9965 000 10710 RES CF 180 OHM 5% 1W AXIAL
R12 9965 000 09682 RES CF 68 OHM 5% 2W AXIAL
R13 9965 000 09685 RES CF 820K OHM 5% 1/4W AXIAL
R15 9965 000 10630 RES MF 1K OHM 1% 1/6W AXIAL
R16 9965 000 10631 RES MF 3.2K OHM 1% 1/6W AXIAL
R17 9965 000 09676 RES CF 2.2 OHM 5% 1/2W AXIAL
COILS & FILTERS
L1 9965 000 10632 IND CHOKE 6.8UH 10% RADIAL
L2 9965 000 10632 IND CHOKE 6.8UH 10% RADIAL
L3 9965 000 09687 LINE CHOKE 100UH 1A 250VAC
L4 9965 000 09687 LINE CHOKE 100UH 1A 250VAC
DIODES
D1 4822 130 30621 1N4148
D3 9965 000 09663 DIODE SR360 3A/60V
D4 5322 130 30684 1N4002RL
D5 5322 130 30684 1N4002RL
DB1 9965 000 09662 BRIDGE RECT. RS202 2A 100V
DB2 4822 130 70035 RS402L
DB4 4822 130 70035 RS402L
TRANSISTORS & INTEGRATED CIRCUITS
Q1 4822 130 42426 2SB772Q
Q2 4822 130 60644 9014C
Q3 4822 130 60644 9014C
Q4 9965 000 09664 TR T8550 PNP HFE 170 1.5A
Q5 4822 130 63082 9015C
U1 4822 209 83824 NJM7805FA
U3 9965 000 06980 PQ3RD13
U4 4822 209 83824 NJM7805FA
U5 9965 000 09690 I.C. NJM7812 VOLT REG 12V 1A
U6 9965 000 09690 I.C. NJM7812 VOLT REG 12V 1A
U7 9965 000 09691 I.C. NJM7912 VOLT REG -12V 1A
U8 9965 000 09692 I.C. PQ1CG3032FZ CHOPPER REGU-
LATOR
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
