Philips MX1060D - Page 27

6-6 6-6
ELECTRICAL PARTS LIST - FRONT BOARD ELECTRICAL PARTS LIST - FRONT BOARD
MISCELLANEOUS
SW1 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW2 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW3 9965 000 10638 ROT ENCODER L=20MM EI602241-2
SW5 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW6 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW7 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW8 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW9 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW10 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW12 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW13 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW14 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW15 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW16 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW17 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW18 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
SW19 9965 000 10149 SW TACT 1P1T 20MA 15V H=5MM
VFD1 9965 000 10151 VFD DISPLAY 25U53103BAN REV.B
X1 9965 000 10147 CRYSTAL 8MHZ 20PPM HC-49U
X2 9965 000 10146 CRYSTAL 32.768KHZ 20PPM DT-38
CAPACITORS
C1 9965 000 10123 CAP CER 0.01UF 50V 20%
C2 9965 000 10122 CAP CER 100PF 50V 10%
C3 9965 000 10122 CAP CER 100PF 50V 10%
C4 9965 000 09654 CAP ELEC GR 10UF 16V 20%
C5 9965 000 09668 CAP ELEC GR 1UF 50V 20%
C6 9965 000 10124 CAP CER 20PF 50V 10% NPO
C7 9965 000 10124 CAP CER 20PF 50V 10% NPO
C8 9965 000 10123 CAP CER 0.01UF 50V 20%
C9 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C10 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C11 9965 000 10123 CAP CER 0.01UF 50V 20%
C12 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C13 9965 000 10124 CAP CER 20PF 50V 10% NPO
C14 9965 000 10124 CAP CER 20PF 50V 10% NPO
C15 9965 000 10123 CAP CER 0.01UF 50V 20%
C16 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C19 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C20 9965 000 10123 CAP CER 0.01UF 50V 20%
C23 9965 000 10125 CAP CER 22PF 50V 5% SL
C24 9965 000 10122 CAP CER 100PF 50V 10%
C25 9965 000 10122 CAP CER 100PF 50V 10%
C26 9965 000 10122 CAP CER 100PF 50V 10%
C27 9965 000 09652 CAP CER 0.1UF 50V +80/-20% Y5V
C36 9965 000 10125 CAP CER 22PF 50V 5% SL
C37 9965 000 10125 CAP CER 22PF 50V 5% SL
C38 9965 000 10118 CAP CER 5PF 50V 0.25P SL
RESISTORS
R1 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R2 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R3 9965 000 09681 RES CF 560 OHM 5% 1/6W AXIAL
R4 9965 000 10134 RES CF 82K OHM 5% 1/6W AXIAL
R5 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R6 9965 000 10133 RES CF 470K OHM 5% 1/6W AXIAL
R7 9965 000 10133 RES CF 470K OHM 5% 1/6W AXIAL
R8 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R9 9965 000 10129 RES CF 2.7K OHM 5% 1/6W AXIAL
R10 9965 000 10132 RES CF 47K OHM 5% 1/6W AXIAL
R11 9965 000 10127 RES CF 12K OHM 5% 1/6W AXIAL
R12 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R13 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R14 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R15 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R16 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R17 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R20 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R21 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R22 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R23 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R29 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R32 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R33 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R34 9965 000 09680 RES CF 4.7K OHM 5% 1/6W AXIAL
R35 9965 000 09680 RES CF 4.7K OHM 5% 1/6W AXIAL
R36 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R37 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R38 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R40 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R42 9965 000 10128 RES CF 220 OHM 5% 1/6W AXIAL
R43 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R44 9965 000 10128 RES CF 220 OHM 5% 1/6W AXIAL
R45 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R46 9965 000 10128 RES CF 220 OHM 5% 1/6W AXIAL
R51 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R53 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R55 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R58 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R59 9965 000 09681 RES CF 560 OHM 5% 1/6W AXIAL
R60 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R61 9965 000 10130 RES CF 33 OHM 5% 1/6W AXIAL
R62 9965 000 10130 RES CF 33 OHM 5% 1/6W AXIAL
R63 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R64 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R65 9965 000 10130 RES CF 33 OHM 5% 1/6W AXIAL
R66 9965 000 10128 RES CF 220 OHM 5% 1/6W AXIAL
R67 9965 000 10130 RES CF 33 OHM 5% 1/6W AXIAL
R68 9965 000 10128 RES CF 220 OHM 5% 1/6W AXIAL
R69 9965 000 10130 RES CF 33 OHM 5% 1/6W AXIAL
R70 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R80 9965 000 10131 RES CF 3.3K OHM 5% 1/6W AXIAL
R91 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R92 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R93 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R94 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R95 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R96 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
COILS & FILTERS
L1 9965 000 10136 IND PEAK 47UH 10% AXIAL
L2 9965 000 10136 IND PEAK 47UH 10% AXIAL
L3 9965 000 10136 IND PEAK 47UH 10% AXIAL
L4 9965 000 10136 IND PEAK 47UH 10% AXIAL
L5 9965 000 10136 IND PEAK 47UH 10% AXIAL
L6 9965 000 10136 IND PEAK 47UH 10% AXIAL
DIODES
D1 9965 000 10138 LED RED RECTANGLE 2R4PD-2
D2 4822 130 30621 1N4148
D3 4822 130 30621 1N4148
D4 4822 130 30621 1N4148
D5 4822 130 30621 1N4148
D6 4822 130 30621 1N4148
D7 4822 130 30621 1N4148
D8 4822 130 30621 1N4148
D9 4822 130 30621 1N4148
D10 4822 130 30621 1N4148
D11 4822 130 30621 1N4148
D12 4822 130 30621 1N4148
D13 4822 130 30621 1N4148
D14 4822 130 30621 1N4148
D15 4822 130 30621 1N4148
D16 4822 130 30621 1N4148
D17 4822 130 30621 1N4148
D18 4822 130 30621 1N4148
D19 4822 130 30621 1N4148
D20 4822 130 30621 1N4148
D21 4822 130 30621 1N4148
D28 4822 130 30621 1N4148
D29 4822 130 30621 1N4148
D30 4822 130 30621 1N4148
D31 9965 000 10140 LED AMBER 5X8.6MM 5O3STAY08
D32 9965 000 10140 LED AMBER 5X8.6MM 5O3STAY08
D33 9965 000 10140 LED AMBER 5X8.6MM 5O3STAY08
D34 9965 000 10140 LED AMBER 5X8.6MM 5O3STAY08
D35 9965 000 10140 LED AMBER 5X8.6MM 5O3STAY08
D36 9965 000 10140 LED AMBER 5X8.6MM 5O3STAY08
Z1 9965 000 10116 ZENER MTZ-J2.2V 1/2W 5%
Z2 4822 130 34173 BZX79-B5V6
TRANSISTORS & INTEGRATED CIRCUITS
Q1 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q2 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q3 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q4 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q5 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q6 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q7 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q8 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q9 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q10 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
Q11 9965 000 10117 TR SS9014 NPN HFE 200 270MHZ
U1 9965 000 10145 I.C. UPD16315 VFD DRIVER
U2 9965 000 10142 I.C. LOGIC PDIL M74HC138BIR
U3 9965 000 10144 IC XL24C04 EEPROM 512B 250NS
U4 9965 000 10141 IR GP1U271R RX 940NM 38KHZ
U5 9965 000 10143 UPD780024GC-513-AB8 8BIT 32K
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
