Philips MX1060D - Page 43

10-4 10-4
ELECTRICAL PARTS LIST - AUDIO SWITCH BOARD
MISCELLANEOUS
JA1 9965 000 09656 RCA SOCKET 4P RED/WHITE
JA2 9965 000 09656 RCA SOCKET 4P RED/WHITE
CAPACITORS
C1* 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C2* 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C3* 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C4* 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
CA1 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA2 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA3 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA4 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA5 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA6 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA7 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA8 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA9 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA10 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA11 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA12 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA13 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA14 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA15 9965 000 09661 CER SMD 470PF 50V 10% X7R 0805
CA16 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA17 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA18 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CA19 9965 000 09660 CER SMD 0,1UF 50V +80-20% 0805
CA20 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CA21 9965 000 09660 CER SMD 0,1UF 50V +80-20% 0805
CA22 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CA23 9965 000 09653 CAP ELEC 1UF 16V 20%
CA24 9965 000 09653 CAP ELEC 1UF 16V 20%
CA25 9965 000 09653 CAP ELEC 1UF 16V 20%
CA26 9965 000 09653 CAP ELEC 1UF 16V 20%
CA27 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA28 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA29 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA30 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA31 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA32 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA33 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA34 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA35 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA36 9965 000 09659 CER SMD 100PF 50V 10% X7R 0805
CA37 9965 000 09660 CER SMD 0,1UF 50V +80-20% 0805
RESISTORS
RA1 4822 051 20008 JUMPER 0R 0805
RA2 4822 051 20474 470K 5% 0,1W
RA3 4822 051 20008 JUMPER 0R 0805
RA4 4822 051 20474 470K 5% 0,1W
RA5 4822 117 11139 1,5K 1% 0,1W
RA6 4822 051 20474 470K 5% 0,1W
RA7 4822 117 11139 1,5K 1% 0,1W
RA8 4822 051 20474 470K 5% 0,1W
RA9 4822 117 11139 1,5K 1% 0,1W
RA10 4822 051 20474 470K 5% 0,1W
RA11 4822 117 11139 1,5K 1% 0,1W
RA12 4822 051 20474 470K 5% 0,1W
RA13 4822 117 11139 1,5K 1% 0,1W
RA14 4822 051 20474 470K 5% 0,1W
RA15 4822 117 11139 1,5K 1% 0,1W
RA16 4822 051 20474 470K 5% 0,1W
RA17 9965 000 09658 RES SMD 47K OHM 5% 1/10W 0805
RA18 4822 117 11449 2,2K 5% 0,1W 0805
RA19 4822 117 11449 2,2K 5% 0,1W 0805
RA20 4822 051 20474 470K 5% 0,1W
RA21 9965 000 09657 RES SMD 2,7K OHM 5% 1/10W 0805
RA22 4822 051 20472 4,7K 5% 0,1W
RA23 4822 051 20102 1K 5% 0,1W
RA24 4822 051 20474 470K 5% 0,1W
RA25 9965 000 09657 RES SMD 2,7K OHM 5% 1/10W 0805
RA26 4822 051 20472 4,7K 5% 0,1W
RA27 4822 051 20102 1K 5% 0,1W
TRANSISTORS & INTEGRATED CIRCUITS
QA1 4822 130 61074 2SA812M5
QA2 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
QA3 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
QA4 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
UA1 4822 209 13648 LC78212
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
* ITEMS THAT ARE SKYMOUNTED & NOT IN THE BOARD
LAYOUT.
