11-4 11-4
ELECTRICAL PARTS LIST - VIDEO SWITCH BOARD
MISCELLANEOUS
J1+J2 9965 000 10155 RCA SOCKET 3P YELLOW
J3 9965 000 10154 RCA SOCKET 2P
CAPACITORS
C1* 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C2* 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
CV1 5322 122 34098 10NF 10% X7R 63V
CV2 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CV3 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CV4 5322 122 34098 10NF 10% X7R 63V
CV5 5322 122 34098 10NF 10% X7R 63V
CV6 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CV7 9965 000 10058 CAP ELEC GR 100UF 16V 20%
CV8 5322 122 34098 10NF 10% X7R 63V
CV9 9965 000 10057 CAP ELEC GR 10UF 25V 20%
CV10 9965 000 10057 CAP ELEC GR 10UF 25V 20%
CV11 9965 000 10057 CAP ELEC GR 10UF 25V 20%
CV12 9965 000 10057 CAP ELEC GR 10UF 25V 20%
CV13 4822 126 13692 47PF 1% NP0 63V
CV14 4822 126 13692 47PF 1% NP0 63V
CV15 4822 126 13692 47PF 1% NP0 63V
CV16 4822 126 13692 47PF 1% NP0 63V
CV17 4822 126 13692 47PF 1% NP0 63V
CV18 4822 126 13692 47PF 1% NP0 63V
CV22 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CV23 9965 000 10158 CER SMD 0,1UF 50V +80-20% 0805
CV24 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CV25 9965 000 09655 CAP ELEC GR 220UF 16V 20%
CV26 9965 000 10158 CER SMD 0,1UF 50V +80-20% 0805
CV27 9965 000 09654 CAP ELEC GR 10UF 16V 20%
CV28 9965 000 10159 CER SMD 270PF 50V 10% X7R 0805
CV29 9965 000 10159 CER SMD 270PF 50V 10% X7R 0805
RESISTORS
RV1 4822 117 11927 75R 1% 0,1W
RV2 4822 117 11927 75R 1% 0,1W
RV3 4822 117 11927 75R 1% 0,1W
RV4 4822 117 11927 75R 1% 0,1W
RV7 4822 117 11927 75R 1% 0,1W
RV8 4822 117 11927 75R 1% 0,1W
RV9 4822 117 11927 75R 1% 0,1W
RV10 9965 000 10157 RES SMD 240 OHM 5% 1/10W 0805
RV11 4822 117 12521 68R 1% 0,1W
RV12 4822 051 20919 91R 5% 0,1W
RV13 4822 117 10353 150R 1% 0,1W
RV14 4822 051 20333 33K 5% 0,1W
RV15 9965 000 10156 RES SMD 12K OHM 5% 1/10W 0805
RV16 9965 000 10157 RES SMD 240 OHM 5% 1/10W 0805
RV17 4822 117 12521 68R 1% 0,1W
RV18 4822 051 20919 91R 5% 0,1W
RV19 4822 117 10353 150R 1% 0,1W
RV20 4822 051 20333 33K 5% 0,1W
RV21 9965 000 10156 RES SMD 12K OHM 5% 1/10W 0805
TRANSISTORS & INTEGRATED CIRCUITS
QV1 9965 000 10110 TR SMD T2907A HFE300 200MHZ
QV2 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
QV3 9965 000 10110 TR SMD T2907A HFE300 200MHZ
QV4 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
UV1 9965 000 10153 IC NJM79L09A VOLT REG 9V 100MA
UV2 9965 000 10152 IC NJM78L09 VOLT REG 9V 100MA
UV3 4822 209 31538 LC7824
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
* ITEMS THAT ARE SKYMOUNTED & NOT IN THE BOARD
LAYOUT.
