ELECTRICAL PARTS LIST - PRO-LOGIC BOARD
MISCELLANEOUS
RCAS19965 000 10073 RCA SOCKET 1P BLACK
RL1 9965 000 10072 RELAY MAINATURE 12VDC/2A 2P1T
CAPACITORS
C1 9965 000 10077 CER SMD 220PF 50V 10% X7R 0805
C2 9965 000 10077 CER SMD 220PF 50V 10% X7R 0805
C3 5322 122 34098 10NF 10% X7R 63V
C4 5322 122 34098 10NF 10% X7R 63V
C5 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C6 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C7 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C8 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C9 9965 000 10063 CAP ELEC SM 0,47µF 16V 20%
C10 9965 000 10063 CAP ELEC SM 0,47µF 16V 20%
C11 9965 000 10066 CAP ELEC GR 0,68µF 50V 10%
C12 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C13 9965 000 10077 CER SMD 220PF 50V 10% X7R 0805
C14 9965 000 10077 CER SMD 220PF 50V 10% X7R 0805
C15 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C16 9965 000 10064 CAP ELEC GR 470UF 16V 20%
C17 9965 000 10059 CAP ELEC GR 1000UF 16V 20%
C18 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C19 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C20 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C21 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C80 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C81 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C83 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C84 4822 126 14585 100NF 10% X7R 0805 50V
C85 4822 126 14585 100NF 10% X7R 0805 50V
C87 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C88 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C90 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C91 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C92 4822 126 14585 100NF 10% X7R 0805 50V
C93 4822 126 14585 100NF 10% X7R 0805 50V
C94 9965 000 09668 CAP ELEC GR 1UF 50V 20%
C95 5322 126 10223 4,7NF 10% X7R 63V
C96 5322 122 34123 CER2 0805 X7R 63V 1N 10PM R
C97 4822 126 14585 100NF 10% X7R 0805 50V
C98 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C99 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C100 4822 126 14585 100NF 10% X7R 0805 50V
C101 5322 126 10223 4,7NF 10% X7R 63V
C102 5322 122 34123 CER2 0805 X7R 63V 1N 10PM R
C103 9965 000 09668 CAP ELEC GR 1UF 50V 20%
C104 9965 000 10081 CER SMD 0,0056UF 50V 10% 0805
C105 9965 000 10080 CER SMD 0,047UF 50V 20% 0805
C107 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C108 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C109 9965 000 10065 CAP ELEC GR 4,7UF 50V 20%
C110 9965 000 10065 CAP ELEC GR 4,7UF 50V 20%
C111 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C112 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C113 4822 126 14585 100NF 10% X7R 0805 50V
C114 9965 000 10080 CER SMD 0,047UF 50V 20% 0805
C115 9965 000 10080 CER SMD 0,047UF 50V 20% 0805
C116 4822 126 14585 100NF 10% X7R 0805 50V
C117 4822 126 14585 100NF 10% X7R 0805 50V
C118 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C119 9965 000 10056 CAP CER 0,22UF 25V 10% Y5V
C120 4822 126 14585 100NF 10% X7R 0805 50V
C121 9965 000 10082 CER SMD 680PF 50V 10% X7R 0805
C122 5322 122 34098 10NF 10% X7R 63V
C123 5322 122 34098 10NF 10% X7R 63V
C124 9965 000 10082 CER SMD 680PF 50V 10% X7R 0805
C125 5322 122 34098 10NF 10% X7R 63V
C126 5322 122 34098 10NF 10% X7R 63V
C127 9965 000 10065 CAP ELEC GR 4,7UF 50V 20%
C128 9965 000 10083 CER SMD 6800PF 50V 10% 0805
C129 9965 000 10065 CAP ELEC GR 4,7UF 50V 20%
C130 9965 000 09655 CAP ELEC GR 220UF 16V 20%
C131 9965 000 10058 CAP ELEC GR 100UF 16V 20%
C132 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C133 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C134 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C135 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C136 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C137 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C138 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C139 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C140 9965 000 10064 CAP ELEC GR 470UF 16V 20%
C141 9965 000 10078 CER SMD 22NF 50V 10% X7R 0805
C143 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C144 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C145 9965 000 10078 CER SMD 22NF 50V 10% X7R 0805
C147 4822 126 12105 CER2 0805 X7R 50V 33NF PM5
C148 4822 126 12105 CER2 0805 X7R 50V 33NF PM5
C149 9965 000 10060 CAP ELEC GR 22UF 16V 20%
C150 9965 000 10060 CAP ELEC GR 22UF 16V 20%
C151 5322 122 34123 CER2 0805 X7R 63V 1N 10PM R
C152 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C153 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C154 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C155 9965 000 10057 CAP ELEC GR 10UF 25V 20%
C156 9965 000 10060 CAP ELEC GR 22UF 16V 20%
C159 4822 126 14585 100NF 10% X7R 0805 50V
C160 4822 126 14585 100NF 10% X7R 0805 50V
C161 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C168 9965 000 10079 CER SMD 47PF 50V 5% NPO 0805
C169 9965 000 10062 CAP ELEC GS 33UF 50V 20%
C170 9965 000 10057 CAP ELEC GR 10UF 25V 20%
CVV 9965 000 09666 CAP CER 0,1UF 100V 20% Y5V
RESISTORS
R1 4822 117 10837 100K 1% 0,1W
R2 4822 117 10837 100K 1% 0,1W
R3 4822 051 20333 33K 5% 0,1W
R4 4822 051 20333 33K 5% 0,1W
R5 4822 117 10837 100K 1% 0,1W
R6 4822 117 10837 100K 1% 0,1W
R7 4822 117 10837 100K 1% 0,1W
R8 4822 117 10837 100K 1% 0,1W
R9 4822 117 10837 100K 1% 0,1W
R10 4822 117 10837 100K 1% 0,1W
R11 9965 000 09658 RES SMD 47K OHM 5% 1/10W 0805
R12 9965 000 09658 RES SMD 47K OHM 5% 1/10W 0805
R13 4822 051 20273 27K 5% 0,1W
R14 4822 051 20273 27K 5% 0,1W
R15 4822 117 11373 100R 1% RC12H 0805
R16 4822 117 11373 100R 1% RC12H 0805
R17 4822 051 20102 1K 5% 0,1W
R18 4822 051 20333 33K 5% 0,1W
R19 9965 000 09658 RES SMD 47K OHM 5% 1/10W 0805
R20 4822 117 10837 100K 1% 0,1W
R21 4822 117 10837 100K 1% 0,1W
R22 4822 117 10965 18K 1% 0,1W
R23 4822 051 20562 5,6K 5% 0,1W 0805
R24 4822 117 10837 100K 1% 0,1W
R25 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R26 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R27 9965 000 10067 RES CF 1,8K OHM 5% 1/6W AXIAL
R28 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R29 9965 000 10067 RES CF 1,8K OHM 5% 1/6W AXIAL
R40 4822 051 20334 330K 5% 0,1W
R41 9965 000 09658 RES SMD 47K OHM 5% 1/10W 0805
R42 4822 051 20154 150K 5% 0,1W
R43 9965 000 10076 RES SMD 75K OHM 5% 1/10W 0805
R44 9965 000 09658 RES SMD 47K OHM 5% 1/10W 0805
R45 4822 051 20154 150K 5% 0,1W
R46 9965 000 10076 RES SMD 75K OHM 5% 1/10W 0805
R47 4822 117 10837 100K 1% 0,1W
R48 4822 117 10837 100K 1% 0,1W
R49 4822 051 20472 4,7K 5% 0,1W
R50 4822 051 20472 4,7K 5% 0,1W
R51 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R52 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R53 4822 051 20182 1,8K 5% 0,1W
R54 4822 051 20182 1,8K 5% 0,1W
R55 9965 000 10075 RES SMD 430 OHM 5% 1/10W 0805
R56 9965 000 10075 RES SMD 430 OHM 5% 1/10W 0805
R59 4822 117 10837 100K 1% 0,1W
R60 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R61 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R62 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R63 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R64 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R65 9965 000 10074 RES SMD 10K OHM 5% 1/10W 0805
R66 4822 051 20333 33K 5% 0,1W
R67 4822 051 20472 4,7K 5% 0,1W
R68 4822 051 20182 1,8K 5% 0,1W
R69 4822 051 20822 8,2K 5% 0,1W
R70 4822 117 11449 2,2K 5% 0,1W 0805
R79 4822 051 20561 560R 5% 0,1W
R80 4822 051 20562 5,6K 5% 0,1W 0805
R81 4822 051 20562 5,6K 5% 0,1W 0805
R82 4822 051 20562 5,6K 5% 0,1W 0805
R83 4822 051 20008 JUMPER 0R 0805
COILS & FILTERS
L1 9965 000 10068 IND CHOKE 1,2µH 10% AXIAL
L2 9965 000 10068 IND CHOKE 1,2µH 10% AXIAL
L3 9965 000 10068 IND CHOKE 1,2µH 10% AXIAL
L4 9965 000 10069 IND CHOKE 470UH 10% AXIAL
L5 9965 000 09687 LINE CHOKE 100UH 1A 250VAC
L6 9965 000 09687 LINE CHOKE 100UH 1A 250VAC
DIODES
D1 4822 130 30862 BZX79-B9V1
D2 4822 130 30621 1N4148
D3 4822 130 30621 1N4148
D4 4822 130 30621 1N4148
DZ1 4822 130 30862 BZX79-B9V1
TRANSISTORS & INTEGRATED CIRCUITS
Q1 4822 130 62718 JE8050C
Q9 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
Q10 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
Q11 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
Q12 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
Q13 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
Q14 9965 000 09651 TR SMD 2SC1623 HFE200 180MHZ
Q15 9965 000 09881 TR 9014C NPN HFE 100 200MHZ
Q16 9965 000 09881 TR 9014C NPN HFE 100 200MHZ
U1 4822 209 16265 BA4558N
U2 4822 209 16265 BA4558N
U3 9965 000 10071 IC M62464FP SOUND PROCESSORS
U4 9965 000 10070 IC M62420FP SOUND PROCESSORS
U5 4822 209 16265 BA4558N
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
