3 OPERATING INSTRUCTIONS
3.2.5 FUNCTION KEYS
This oscilloscope features the possibility to select several functions with a single
key in sequential order. To obtain the correct function it is necessary to press
the particular key repeatedly until the correct function is visible in the LCD. After
the last function in line, the sequence starts again. An overview of the functions
is given below. The positions of the keys in this picture are according their actual
positions on the front panel of the oscilloscope.
