CONTENTS • II
3.2.1 FRONTPANEL LAY OUT.3 - 2
3.2.2 SCREEN CONTROLS.3 -2
3.2.3 VIEWING AREA.3 . 3
3.2.4 UP-DOWN KEYS.3 - 4
3.2.6 F UNCTION KEYS.3 - 7
3.2.6 ROTARY KNOBS. 3.9
3.2.7 SOFTKEYS. 3 - 10
3.2.6 INPUTS AND OUTPUTS. 3-12
4 APPLICATIONS 4.1
4.1 USE AS AN ANALOG OSCILLOSCOPE. 4 - 1
4.1.1. VERTICAL MODE. 4-2
4.1.2. HORIZONTAL MODE.... 4 - 8
4.1.3. TRIGGER MODE. 4 - 10
4 2 USE AS A DIGITAL STORAGE OSCILLOSCOPE.4- I 8
4.2.1. VERTICAL MODE.. 4 - 13
4.2.2. HORIZONTAL MODE. 4 - 22
4.2.3. TRIGGER MODE.. 4 - 28
4.3 MENUS AND MEASUREMENTS. 4-34
4.3.1 EXPLANATION OF MENU-STRUCTURES. 4 - 34
4.3.2 PERFORMING AMPLITUDE MEASUREMENTS. ...4 - 46
4.3.3 PERFORMING TIME MEASUREMENTS.4 - 50
4.3.4 ZOOM AND AUTO ZOOM FUNCTIONS.4 - 54
4.3.5 WAVE FORM COMPARISON. 4 . 5 8
5 PLOTTING AND PRINTING 5 . 1
5.1 INTRODUCTION. 5 . 1
5.2 ANALOG PLOT OUT TO XY RECORDERS.5 - 2
5.3 PLOT AND PRINT VIA tEEE-488 INTERFACE. 5 - 4
5.4 PLOT AND PRINT VIA RS-232C INTERFACE.5 - 6
5.5 PLOTTING OR PRINTING RESULTS. 5 - 9
