Mechanical Instructions
EN 16 Q552.2L LA4.
2012-Mar-16
back to
div. table
Figure 4-8 Cable dressing 47PFL8606D/7x (Sundance)
4.2 Service Positions
For easy servicing of a TV set, the set should be put face down
on a soft flat surface, foam buffers or other specific workshop
tools. Ensure that a stable situation is created to perform
measurements and alignments. When using foam bars take
care that these always support the cabinet and never only the
display. Caution: Failure to follow these guidelines can
seriously damage the display!
Ensure that ESD safe measures are taken.
