Philips Q552.2L - Mechanical Instructions; 0 Chapter 2: Table 2-1 Updated (Added Ctns); 0 Chapter 4: Added Wiring Diagrams; See Section 4.1; 0 Chapter 7: Added Ambilight; See Section 7.8

Mechanical Instructions
EN 9Q552.2L LA 4.
2012-Mar-16
back to
div. table
4. Mechanical Instructions
Index of this chapter:
4.1
Cable Dressing
4.2 Service Positions
4.3 Assy/Panel Removal Berlinale styling (xxPFL5806D/78)
4.4 Assy/Panel Removal Blockbuster/Emmy Styling (xxPFL6/
7xxx/xx series)
4.5 Assy/Panel Removal Sundance Styling (xxPFL8xxx/xx
series)
4.6 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing
Figure 4-1 Cable dressing 32PFL6606D/7x (Blockbuster)
19111_012_110519.eps
110519
Tape (150 m.m.) 2 ×
Tape (80 m.m.) 9 ×
Clamp (11 m.m.) 2 ×
