Philips Q552.2L - Sundance 42 - 47

EN 202Q552.2L LA 11.
Styling Sheets
2012-Mar-16
back to
div. table
11.3 Sundance 42" - 47"
19110_064_110711.eps
110711
SUNDANCE 42" - 47"
Pos No. Description Remarks
0004 Front Cabinet
0011 Back Cover
0029 Main Switch Bracket
0035 Swivel bracket
0050 Ambilight Clip 42”
0051 Ambilight Clip 47”
0257 Stand neck
0258 Stand base
0270 3D glasses Not displayed
1004 Display panel
1005 Power Supply Unit
1027 Temperature sensor board
1085 Remote control Not displayed
1108 Keyboard assy (touch control)
1150 Board SSB
1163 Ambilight module
5213 Loudspeake
r box
5216 Tweeter
5217 Tweeter
8191 Mainscord Not displayed
8308 Main Switch with cable
8G50 LVDS (FFC) Cable Not displayed
8G51 LVDS (FFC) Cable Not displayed
1108
0004
1004
5216
1163
0050
0258
0257
0011
5213
0035
0029
8308
1150
1005
5217
1163
0050
0051
0050
0050
00500051
