6.4.6 Option Bit Overview
For test purposes, please find below an overview of the Option
Codes on bit level. With a bin/dec converter, you can calculate
the Option Code.
Caution
When manipulating option codes, know what you’re doing.
Wrong option codes could damage the set.
Prescribed option codes below are an example, not valid for all
sets and are subject to modification.
The correct option codes are always present on a sticker inside
the set!
Table 6-11 Option codes at bit level (Option 1 - Option 8)
Option & Bit Dec. Value Option Name Prescribed Value
1)
Description
Option 1 (prescribed value 32776
1)
)
Bit 15 (MSB) 32768 Video Store Streaming 1
1)
0 = OFF
1 = ON
Bit 14 16384 Multi App 00
1)
00 = none
01 = multi app (Multiview BASIC)
10 = AVPIP + multi app (Multiview ENHANCED)
11 = future use
Bit 13 8192
Bit 12 4096 Perfect Pixel 00
1)
00 = Pixel Plus HD
01 = Pixel Precise HD
10 = Perfect Pixel HD
11 = future use
Bit 11 2048
Bit 10 1024 Tuner Type 000
1)
000 = TH2603 (Europe/AP)
001 = FA2307 (Brazil)
010 = VA1E1ED2411
011 = future use
100 = future use
101 = future use
110 = future use
111 = future use
Bit 9 512
Bit 8 256
Bit 7 128 PQ Profiles 000
1)
000 = profile 0
001 = profile 1
010 = profile 2
011 = profile 3
100 = profile 4
101 = profile 5
110 = profile 6
111 = profile 7
Bit 6 64
Bit 5 32
Bit 4 16 DNM 01
1)
00 = Perfect Natural Motion
01 = HD Natural Motion
10 = future use
11 = future use
Bit 3 8
Bit 2 4 MOP AL 0
1)
CPLD, not used in 2011
Bit 1 2 AL Optical Syst 00
1)
00 = 140 nit
01 = 200 nit
10 = future use
11 = future use
Bit 0 (LSB) 1
Option 2 (prescribed value 00001
1)
)
Bit 15 (MSB) 32768 AL Shop Mode 0
1)
0 = boost mode in shop is OFF
1 = boost mode in shop is ON
Bit 14 16384 AL settings storage location 0
1)
0 = stored in AL modules
1 = stored in SSB
Bit 13 8192 Wall Adaptive AL 0
1)
0 = OFF
1 = ON
Bit 12 4096 Sunset 0
1)
0 = OFF
1 = ON
Bit 11 2048 Ambient Light 0000
1)
0000 = none
0001 = 2-sided (3/3)
0010 = 2-sided (4/4)
0011 = 2-sided (5/5)
0100 = 2-sided (6/6)
0101 = 2-sided (7/7)
0110 = 3-sided (5/5/5)
0111 = 3-sided (6/6/6)
1000 = 3-sided (3/6/3)
1001 = 3-sided (6/9/6)
1010 = 2-sided (8/8)
1011 = 3-sided (4/4/4)
1100 = 2-sided (1/1)
1101 = 2-sided (2/2)
1110 = future use
1111 = future use
Bit 10 1024
Bit 9 512
Bit 8 256
Bit 7 128 FPGA3Dact/1Ddimm 0
1)
0 = OFF
1 = ON
Bit 6 64 AL Select 0
1)
0 = AL2k10
1 = AL2k11
Bit 5 32 3D Passive 0
1)
0 = 2D
1 = 3D passive
Bit 4 16 Smart Bit Enhancement (SBE) 0
1)
0 = off
1 = on (200 Hz board present)
Bit 3 8 Super Resolution 0
1)
0 = Super Resolution SD
1 = Super Resolution HD
