Philips Q552.2L - Page 49

Alignments
EN 49Q552.2L LA 6.
2012-Mar-16
back to
div. table
Bit 10 1024 DVB-S 0
1)
0 = OFF
1 = ON (ATSC/DVB should be ON)
Bit 9 512 DVB-C 1
1)
0 = OFF
1 = ON (ATSC/DVB should be ON)
Bit 8 256 DVB 1
1)
0 = analogue only
1 = DVBT (and C/S depending DVBC/S option)
Bit 7 128 Display Type 01000111
1)
Display Type (ex.: 327)
Bit 6 64
Bit 5 32
Bit 4 16
Bit 3 8
Bit 2 4
Bit 1 2
Bit 0 (LSB) 1
Option 6 (prescribed value 36615
1)
)
Bit 15 (MSB) 32768 E-sticker 1
1)
0 = OFF
1 = ON
Bit 14 16384 Hotel Mode 00
1)
00 = OFF
01 = 1V1
10 = 1V2
11 = future use
Bit 13 8192
Bit 12 4096 Virgin 0
1)
0 = ON
1 = OFF
Bit 11 2048 USB Time Shift 1
1)
0 = OFF
1 = ON
Bit 10 1024 Auto Store Mode 11
1)
00 = none
01 = PDC_VPS
10 = TXT page
11 = PDC_VPS_TXT
Bit 9 512
Bit 8 256 PVR 1
1)
0 = OFF
1 = ON
Bit 7 128 Ginga 00
1)
00 = OFF
01 = Country dependent
10 = ON
11 = future use
Bit 6 64
Bit 5 32 MHP 00
1)
00 = OFF
01 = Country dependent
10 = ON
11 = future use
Bit 4 16
Bit 3 8 Over the Air Download 01
1)
00 = OFF
01 = Country dependent
10 = ON
11 = future use
Bit 2 4
Bit 1 2 DVBC light 1
1)
0 = OFF
1 = ON (when DVBC Installation is OFF or when ON but selected
country is OFF, this option is used)
Bit 0 (LSB) 1 DVBT light 1
1)
0 = OFF
1 = ON (when DVBT Installation is OFF or Country depend to a
country is OFF, this option is used)
Option 7 (prescribed value 33024
1)
)
Bit 15 (MSB) 32768 Visual Identity 1
1)
0 = User Interface 2k10
1 = User Interface 2k11
Bit 14 16384 Red LED Config LUT 000
1)
000 = LED config LUT 0
001 = LED config LUT 1
010 = LED config LUT 2
011 = LED config LUT 3
100 = LED config LUT 4
101 = LED config LUT 5
110 = LED config LUT 6
111 = LED config LUT 7
Bit 13 8192
Bit 12 4096
Bit 11 2048 Board Identifier 00
1)
not used, should always be “00”
Bit 10 1024
Bit 9 512 Manet 0
1)
0 = all sets except Manet
1= Manet
Bit 8 256 Auto Power Down 1
1)
0 = OFF
1 = ON
Bit 7 128 Light Guide 0
1)
0 = OFF
1 = ON
Bit 6 64 E-box 0
1)
0 = integrated set
1 = e-box/monitor
Bit 5 32 Temp LUT 000
1)
000 = temp lut 0
001 = temp lut 1
010 = temp lut 2
011 = temp lut 3
100 = future use
101 = future use
110 = future use
111 = future use
Bit 4 16
Bit 3 8
Bit 2 4 Temp Sensor 00
1)
00 = no temp sensor
01 = temp sensor in display
10 = temp sensor on additional board
11 = temp sensor in AL module
Bit 1 2
Option & Bit Dec. Value Option Name Prescribed Value
1)
Description
