Philips Respironics SimplyGo User Manual

8
SimplyGo User Manual
Symbol TiTle and meaning Reference
Atmospheric Pressure Limitation
Indicates the acceptable upper and lower
limits of atmospheric pressure�
IEC 60878 2621
Temperature limit
Indicates the storage temperature limits
to which the medical device can be safely
exposed�
IEC 60878 0632
Alarm Silence
Turns the audible alarm o�
IEC 60878 5576
Increases the displayed setting __
REF
Model number IEC 60878 2493
SN
Serial number IEC 60878 2498
Therapy on/o (Stand-by)
Identies the button to turn therapy on or
o (puts the device in a stand-by condition)�
IEC 60878 5009
Mode
Selects one of the three possible operating
states of the device�
__
Decreases the displayed setting� __
Manufacturer IEC 60878 3082
For Airline Use Complies with RTCA/DO-160G
section 21, category M�
RTCA/DO-160G
Note: Also see the section on alarm indicators and screen symbols�

Philips Respironics SimplyGo Specifications

General

Weight	10 lbs (4.5 kg) with battery
Continuous Flow Setting	0.5, 1, 1.5, 2 LPM
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Oxygen Flow	Continuous Flow and Pulse Dose
Pulse Dose Setting	1, 2, 3, 4, 5, 6
Power Source	AC/DC power supply, rechargeable battery
Dimensions	11.5 in x 10 in x 6 in
Operating Modes	Continuous flow, pulse dose
Battery Type	Lithium Ion
AC Power Input	100-240 VAC, 50/60 Hz
DC Power Input	11.5 to 16 VDC
Humidity Range	15% to 95% non-condensing
Altitude Range	Up to 10, 000 ft (3048 m)
Warranty	3 years
