Philips Respironics SimplyGo User Manual

22
SimplyGo User Manual
Alarm Indicators and Screen Symbols
Note: All SimplyGo alarms are low priority alarms� The alarm system should
be veried before use and between users by service personnel in
accordance with the SimplyGo service manual�
Technical Alarms
Visual, Audio
Indicators
Description What To Do
A sequence of
3 short
beeps
+
1 long beep
that repeats every
4 seconds
No Breath Alarm
This alarm occurs
when a breath is not
detected for a period
of 2 minutes or more�
It can be silenced by
pressing the Alarm
symbol� This alarm
resets itself as soon as
a breath is detected� If
no breath is detected
after approximately
30 minutes, the device
shuts down to conserve
power�
Note: This alarm is
inactive for ten minutes
after startup� Upon
startup, this alarm could
take a maximum of 12
minutes to activate
from the time the alarm
condition is present�
Otherwise, it can take
up to 2 minutes to
activate�
Check the connection
from the cannula to
the device�
Make sure the nasal
cannula is properly
positioned on your
face and that you are
breathing through
your nose�
Make sure the
cannula tubing is not
kinked or obstructed�

Philips Respironics SimplyGo Specifications

General

Weight	10 lbs (4.5 kg) with battery
Continuous Flow Setting	0.5, 1, 1.5, 2 LPM
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Oxygen Flow	Continuous Flow and Pulse Dose
Pulse Dose Setting	1, 2, 3, 4, 5, 6
Power Source	AC/DC power supply, rechargeable battery
Dimensions	11.5 in x 10 in x 6 in
Operating Modes	Continuous flow, pulse dose
Battery Type	Lithium Ion
AC Power Input	100-240 VAC, 50/60 Hz
DC Power Input	11.5 to 16 VDC
Humidity Range	15% to 95% non-condensing
Altitude Range	Up to 10, 000 ft (3048 m)
Warranty	3 years
