Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
37
1-676-331-11 ENCODER BOARD
**************
< VARIABLE RESISTOR >
RV801 1-466-336-21 ENCODER, ROTARY (TUNING/SELECT)
************************************************************
1-676-332-11 KEY SW BOARD
*************
< CAPACITOR >
C809 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C810 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN804 1-779-495-11 PLUG, CONNECTOR PIN 4P
CN805 1-506-468-11 PIN, CONNECTOR 3P
< RESISTOR >
R831 1-249-425-11 CARBON 4.7K 5% 1/4W F
R832 1-249-427-11 CARBON 6.8K 5% 1/4W F
R833 1-249-429-11 CARBON 10K 5% 1/4W
R834 1-249-433-11 CARBON 22K 5% 1/4W
< SWITCH >
S810 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
S811 1-762-875-21 SWITCH, KEYBOARD (PTY)
S812 1-762-875-21 SWITCH, KEYBOARD (MENU)
S813 1-762-875-21 SWITCH, KEYBOARD (ENTER)
************************************************************
A-4428-528-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C102 1-119-824-11 ELECT MELF 10uF 20% 50V
C103 1-162-294-31 CERAMIC 0.001uF 10% 50V
C104 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C105 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C106 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C107 1-119-824-11 ELECT MELF 10uF 20% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-162-209-31 CERAMIC 27PF 5.00% 50V
C111 1-164-159-11 CERAMIC 0.1uF 50V
C112 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-128-834-11 ELECT 470uF 20% 10V
C117 1-162-203-31 CERAMIC 15PF 5.00% 50V
C118 1-164-159-11 CERAMIC 0.1uF 50V
C119 1-164-159-11 CERAMIC 0.1uF 50V
C120 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-164-159-11 CERAMIC 0.1uF 50V
C122 1-164-159-11 CERAMIC 0.1uF 50V
C123 1-164-159-11 CERAMIC 0.1uF 50V
C124 1-164-159-11 CERAMIC 0.1uF 50V
C125 1-164-159-11 CERAMIC 0.1uF 50V
C126 1-164-159-11 CERAMIC 0.1uF 50V
C127 1-127-718-91 ELECT MELF 100uF 20% 16V
C128 1-128-835-91 ELECT 1000uF 20% 10V
C129 1-164-159-11 CERAMIC 0.1uF 50V
C130 1-128-840-11 ELECT 47uF 20% 16V
C131 1-128-840-11 ELECT 47uF 20% 16V
C132 1-162-219-31 CERAMIC 68PF 5.00% 50V
C133 1-128-840-11 ELECT 47uF 20% 16V
C134 1-127-721-11 ELECT 1000uF 20% 16V
C135 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C136 1-119-820-11 ELECT 1uF 20% 50V
C137 1-128-835-91 ELECT 1000uF 20% 10V
C201 1-162-211-31 CERAMIC 33PF 5% 50V
C202 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C203 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C204 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C205 1-136-161-00 MYLAR 0.047uF 5.00% 50V
C206 1-102-973-00 CERAMIC 100PF 5% 50V
C207 1-102-508-91 CERAMIC 10PF 0.50PF 50V
C208 1-102-518-11 CERAMIC 33PF 5.00% 50V
C209 1-102-516-11 CERAMIC 27PF 5.00% 50V
C210 1-164-159-11 CERAMIC 0.1uF 50V
C211 1-119-824-11 ELECT MELF 10uF 20% 50V
C212 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C213 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C214 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C215 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C216 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C217 1-162-211-31 CERAMIC 33PF 5% 50V
C218 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C219 1-128-840-11 ELECT 47uF 20% 16V
C220 1-128-840-11 ELECT 47uF 20% 16V
C221 1-119-817-11 ELECT 0.22uF 20.00% 50V
C222 1-128-840-11 ELECT 47uF 20% 16V
C223 1-119-820-11 ELECT 1uF 20% 50V
C224 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C225 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C226 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C227 1-119-820-11 ELECT 1uF 20% 50V
C228 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C229 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C230 1-128-840-11 ELECT 47uF 20% 16V
C231 1-162-282-31 CERAMIC 100PF 10% 50V
C232 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C233 1-162-294-31 CERAMIC 0.001uF 10% 50V
C234 1-128-840-11 ELECT 47uF 20% 16V
C235 1-119-820-11 ELECT 1uF 20% 50V
C236 1-162-294-31 CERAMIC 0.001uF 10% 50V
C237 1-128-856-11 ELECT 3.3uF 20% 50V
C238 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C239 1-162-282-31 CERAMIC 100PF 10% 50V
C240 1-130-471-00 MYLAR 0.001uF 5% 50V
C241 1-162-294-31 CERAMIC 0.001uF 10% 50V
C242 1-162-294-31 CERAMIC 0.001uF 10% 50V
C243 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C244 1-162-294-31 CERAMIC 0.001uF 10% 50V
C245 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C246 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C247 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C248 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C249 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C250 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C251 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C252 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
ENCODER KEY SW MAIN
